Min-ETune

Min-ETune™ MANUAL

v 1.0

Table of Contents

Need help?

Do you have a question about the Min-ETune and is the answer not in the manual?

Questions and answers

Summary of Contents for American Musical Min-ETune

Page 1 Min-ETune Min-ETune™ MANUAL Min-ETune™ MANUAL v 1.0 v 1.0...
Page 2 STArT To TuNE 9-11 MUlTI-STRING / SINGle-STRING TUNING SwITch beTweeN bANkS eXAMPle bANk OVeRVIew FuNCTIoN MENu STRING UP ANd dOwN MOde cUSTOM TUNING | SAVING 17-18 RefeReNce TUNING bATTeRY leVel Min-ETune™ - rEplACE BATTEry / ChArGING ThE BATTEry 21-23 lEGAl INForMATIoN www.GIbSON.cOM...
Page 3 Min-ETune™ - ovErvIEw 6 roBohEADS wITh NEw SurFACE loCKING MEChANISM TuNE CoNTrollEr INTEGrATED lED-DISplAy (up, DowN, lEFT, rIGhT, ENTEr) MENU (6 STrING lEDS, 1 MENu lED, 1 ChArGE lEvEl lED) oN/oFF/BACK BATTEry EXChANGEABlE, rEChArGEABlE 3.7 volTS, lI-polyMEr, ApproX. 300 TuNINGS...
Page 4 TuNE CoNTrollEr MENU lEFT rIGhT ENTEr/oK Push and hold the ”off-button“ oN/oFF/BACK to switch off the system. DowN : Battery is full Charged : string in tUnE : Battery is empty : function menu : Frequency out oF pitch WindoW : system configuration : respective robohead is in movement : frequency measurement in progress...
Page 5: Getting Started
GETTING STArTED STrING your GuITAr www.GIbSON.cOM...
Page 6 GETTING STArTED how To uSE ThE STrING ShAFT wITh SurFACE loCKING MEChANISM loCK NuT: YOU Need The lOck NUT TO TIGhTeN The STRING. STrING ShAFT: The STRING ShAfT wINdS The STRING. STrING rECESS: The STRING ReceSS GUIdeS The STRING. loCK NuT STrING rECESS STrING ShAFT www.GIbSON.cOM...
Page 7 GETTING STArTED how To uSE ThE STrING ShAFT 90° ScRew Off The lOck NUT ANd PUll TIGhT ON The STRING TO GeT MeRGe The STRING UP TROUGh The beNd The STRING AROUNd The MAke SURe ThAT The ReceSS IS AT PReTeNSION ANd beNd IT ONe hAlf STRING ReceS TOwARdS The ThReAd.
Page 8 GETTING STArTED how To uSE ThE STrING ShAFT TIGhTeN The lOck NUT All The cUT The eNd Of The STRING clOSe wAY dOwN wITh helP Of A SMAll TO The STRING ShAfT. cOIN. The STRING MUST eNcIRcle The STRING ShAfT cOMPleTelY. www.GIbSON.cOM...
Page 9 GETTING STArTED how To TuNE/ADDITIoNAl INForMATIoN www.GIbSON.cOM...
Page 10 GETTING STArTED how To TuNE/ADDITIoNAl INForMATIoN rE-TuNING fOR ReTUNING, STRUM All STRINGS IN The MANNeR YOU dId IN cAlIbRATION MOde (pAGE 28) (STRUM bY ThUMb, clOSe TO The Neck jOINT (SOUNd hOle), 1 STRUM = All STRINGS wIThIN 1 Sec.) wAIT 3-5 SecONdS beT weeN T wO STRUMS AfTeR STRUMMING, MUTe STRINGS ThAT ARe AlReAdY IN TUNe (GReeN led ON TUNe cONROlleR) ANd STRUM The NOT TUNed STRINGS ONlY.
Page 11: Start To Tune
STArT To TuNE www.GIbSON.cOM...
Page 12 STArT To TuNE TuNE MoDE - MulTI-STrING TuNING PReSS ”oN”. The MUlTI-STRING MOde cOMeS UP wITh The lAST cOMPleTed TUNING. MENU ENTEr PIck All STRINGS AT ONce - TUNING beGINS. PIck STRINGS AGAIN If TheY ARe NOT IN TUNe (Red). MUTe STRINGS ThAT ARe AlReAdY IN TUNe (GReeN).
Page 13 STArT To TuNE TuNE MoDE - SINGlE-STrING TuNING PReSS & hOld ”oN”. The SINGle-STRING MOde cOMeS UP wITh The lAST cOMPleTed TUNING. MENU If YOU ARe IN TUNING SelecTION MOde AlReAdY, SelecT deSIRed PReSeT. TheN PReSS & hOld “ENTEr“ fOR SINGle-STRING TUNING. PIck oNE STrING AFTEr ANoThEr AS INdIcATed, UNTIl All STRINGS ARe IN TUNe (GReeN).
Page 14 STArT To TuNE TuNING SElECTIoN SwITCh BETwEEN rED, GrEEN AND BluE BANK PReSS ”ON”. The MUlTI-STRING MOde cOMeS UP wITh The lAST cOMPleTed TUNING. MENU NOw PReSS ”BACK” ON The TUNe cONTROlleR fOR TUNING SelecTION. The MeNU led wIll SwITch Off. oN/BACK MENU PReSS ”up“...
Page 15 STArT To TuNE TuNING SElECTIoN EXAMplE: “opEN G“ MAjor ChorD PUSh “oN“ bUTTON, The SYSTeM wIll cOMe UP wITh The lAST cOMPleTed TUNING. TheN PUSh “BACK“ (SAMe bUTTON) TO MENU eNTeR TUNING SelecTION MOde. The MeNU led SwITcheS Off. oN/BACK PUSh ”up“...
Page 16 STArT To TuNE TuNING SElECTIoN bANk OVeRVIew bANk “STANdARd“ MENU “dAdGAd“ “lOw d“ “dROP-d“ “e “ rED BANK TuNINGS “dOUble dROP-d“ GReeN bANk “OPeN e“ MENU “OPeN A“ “OPeN d“ “OPeN G“ “dObRO“ GrEEN BANK TuNINGS “All 4 “ blUe bANk “USeR-defINed 01“...
Page 17: Function Menu
FuNCTIoN MENu FuNCTIoN ovErvIEw STRING UP ANd dOwN MOde / cUSTOM TUNING / RefeReNce TUNING / fIRMwARe VeRSION / bATTeRY leVel PUSh “oN“ bUTTON. The SYSTeM cOMeS UP wITh The lAST cOMPleTed TUNING IN MUlTI-STRING MOde. PUSh “BACK“ bUTTON MENU TO eNTeR TUNING SelecTION MOde.
Page 18 FuNCTIoN MENu STrING up AND DowN MoDE fOR ReSTRINGING YOUR GUITAR PUSh “oN“ bUTTON. The SYSTeM cOMeS UP wITh The lAST cOMPleTed TUNING IN MUlTI-STRING MOde. PUSh “BACK“ bUTTON MENU ENTEr TO eNTeR TUNING SelecTION MOde. MeNU led IS Off. TO eNTeR fUNcTION MeNU PReSS ANd hOld The “up“...
Page 19: Custom Tuning
FuNCTIoN MENu CuSToM TuNING TUNe YOUR GUITAR MANUAllY TO ANY TUNING ThAT YOU wISh TO SAVe ON A PReSeT POSITION (blUe bANk) MENU ENTEr PUSh “oN“ bUTTON. The SYSTeM cOMeS UP wITh The lAST cOMPleTed TUNING IN MUlTI-STRING MOde. PUSh “BACK“ bUTTON TO eNTeR TUNING SelecTION MOde.
Page 20 FuNCTIoN MENu CuSToM TuNING | SAvING UPON cOMPleTION Of MeASUReMeNT The SYSTeM SwITcheS TO The blUe bANk AUTOMATIcAllY INdIcATed MENU ENTEr bY The blUe flAShING led. PUSh “lEFT/rIGhT“ TO SelecT ONe Of SIX PReSeT lEFT / rIGhT POSITIONS (e-e) ANd PUSh “eNTeR“ TO SAVe YOUR TUNING. BACK SElECT prESET To SAvE All STRING ledS wIll flASh UP GReeN T wO TIMeS fOR...
Page 21 FuNCTIoN MENu rEFErENCE TuNING SeqUeNce TUNe The GUITAR TO The deSIRed TUNING PReSeT. chANGe The PITch Of ONe STRING (RefeReNce STRING) MENU ENTEr bY MANUAllY TURNING The keY. eNTeR ANd eXecUTe RefeReNce MOde TO eNTeR RefeReNce TUNING MOde: PUSh “oN“ bUTTON. The SYSTeM cOMeS UP wITh The lAST cOMPleTed TUNING IN MUlTI-STRING MOde.
Page 22: Battery Level
BATTEry lEvEl FuNCTIoN MENu PUSh “oN“ bUTTON. The SYSTeM cOMeS UP wITh The lAST cOMPleTed TUNING IN MUlTI-STRING MOde. PUSh “BACK“ bUTTON MENU ENTEr TO eNTeR TUNING SelecTION MOde. MeNU led IS Off. PReSS ANd hOld The “up“ bUTTON UNTIl MeNU led INdIcATeS whITe. USe “lEFT/rIGhT“...
Page 23 Min-ETune™ rEplACE BATTEry/ChArGE BATTEry www.GIbSON.cOM...
Page 24: Replace Battery
Min-ETune™ rEplACE BATTEry prESS oN ThE BATTEry pull ouT ThE BATTEry To rElEASE. MENU MENU www.GIbSON.cOM...
Page 25: Charge The Battery
Min-ETune™ ChArGE ThE BATTEry BATTEry pACK lI-polyMEr ChArGEr 3.7v 340mAh 1258mWh li-polyMEr iNpUT: Ac100-240v 50/60hz oUTpUT: 4.2v – 300mA A BAT TEry ThAT hAs BEEN iNfrEqUENTly UsEd, or A NEW oNE, coUld hAvE rEdUcEd cApAciTy. yoU MAy NEEd To rEchArgE iT A NUMBEr of TiMEs.
Page 26: Legal Information
The battery in your Min-ETune™ must be disposed of properly and should never be placed in municipal waste.
