Summary of Contents for Jumbuck Chiminea
-
Page 4: Tools Required
*This chiminea will become very hot during use and for some time after use. Keep children away from the chiminea and do not touch metal parts of the chiminea when in use. Use suitable gloves for protection, especially when loading the chiminea with logs or coal. - Page 5 STEP 1 Place stove bottom (7) on its side and attach three legs (9) using nine bolt M6X25mm and nuts. Tighten securely. STEP 2 Insert two Grates (12) in the Stove Bottom (7). Attach three Connector plates-3 (6) to stove bottom (7) using three Bolt M6X20mm and Nuts.
- Page 6 Attach the Hook (10) on left side of the mesh stove assembly (5) using a nut. STEP 4 Install Mesh Stove Assembly (5) on Stove Bottom assembly from previous steps. Align connector plates and fasten using three Bolt M6X20mm and Nuts.
- Page 7 STEP 5 Install stove top (4) on mesh stove assembly (5) . Align the holes on the top with the holes in the connector plates and connect using three Bolt M6X25mm and Nuts. Leave loosely tightened. STEP 6 Connect lower flue (3) to stove top (4) using three Bolt M6X25mm and Nuts. Secure all bolts from previous steps, but do not over tighten.
- Page 8 STEP 7 Attach upper flue (2) to lower flue (3) using three Bolt M6X20mm . Tighten securely. STEP 8 Place Cap and Spark Arrestor Screen into Upper Flue as shown...
- Page 9 (5) . Be sure to tighten all loose of the loose screws in steps 1-8. Your Chiminea is now ready for use. Please take care when lighting your Chiminea. Always keep children away from this Chiminea at all...
-
Page 10: Warranty
• Any repair does not extend the warranty repaired or replaced if the goods fail to be of period. acceptable quality and the failure does not amount to • Any parts other than original Jumbuck parts a major failure. will void this warranty. For New Zealand Customer... -
Page 11: For Technical Assistance
JUMBUCK damage during transit if at the time the product CHIMINEA, in the first instance review the was being transported by Bunnings or a instructions manual or contact your local Bunnings Bunnings approved contractor. warehouse Lack of maintenance, abuse, neglect, misuse,...
