Garmin TD 50 Installation Instructions

TD 50
INSTALLATION
INSTRUCTIONS
Important Safety Information
WARNING
See the Important Safety and Product Information guide in the product box for
product warnings and other important information.
CAUTION
Always wear safety goggles, ear protection, and a dust mask when drilling,
cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite side of the
surface.
Mounting Considerations
NOTICE
This device should be mounted in a location that is not exposed to extreme
temperatures or conditions. The temperature range for this device is listed in
the product specifications. Extended exposure to temperatures exceeding the
specified temperature range, in storage or operating conditions, may cause
device failure. Extreme-temperature-induced damage and related
consequences are not covered by the warranty.
The mounting surface must be flat to avoid damaging the device when it is
mounted.
Using the included hardware and template, you can flush mount the device in
the dashboard. If you want to mount the device using an alternative method
where it appears flat with the front of the dashboard, you must purchase a flat-
mount kit (professional installation recommended) from your Garmin
When selecting a mounting location, observe these considerations.
• The mounting location should be at or below eye level to provide optimal
viewing as you operate your vessel.
• The mounting surface must be strong enough to support the weight of the
device and protect it from excessive vibration or shock.
• To avoid interference with a magnetic compass, the device should not be
installed closer to a compass than the compass-safe distance value listed
in the product specifications.
• The area behind the mounting surface must allow room for the routing and
connection of the cables.
Mounting the Device
NOTICE
Be careful when cutting the hole to flush mount the device. There is only a
small amount of clearance between the case and the mounting holes, and
cutting the hole too large could compromise the stability of the device after it is
mounted.
To avoid potential damage to the powder coating, use only the included
screws to mount the device. Using screws other than the ones included will
void your warranty.
The included template and hardware can be used to flush mount the device in
your dashboard. There are three options for hardware based on the mounting
surface material.
• You can drill pilot holes and use the included wood screws.
• You can drill holes and use the included nut plates and machine screws.
The nut plates can add stability to a thinner surface.
• You can punch holes, tap them to M3, and use the included machine
screws.
1
Trim the template and make sure it fits in the location where you want to
mount the device.
2
Secure the template to the selected location.
9
3
Using a 3.6 mm ( /
64
corners of the solid line on the template to prepare the mounting surface
for cutting.
4
Using a jigsaw or rotary tool, cut the mounting surface along the inside of
the solid line indicated on the template.
5
Place the device in the cutout to test the fit.
6
If necessary, use a file and sandpaper to refine the size of the cutout.
7
After the device fits correctly in the cutout, ensure the mounting holes on
the device line up with the larger 7.2 mm (
8
If the mounting holes on the device do not line up, mark the new hole
locations.
9
Based on your mounting surface, drill or punch and tap the larger holes:
1
• Drill 3.2 mm ( /
8
to step 18.
9
• Drill 7.2 mm ( /
32
screws.
• Punch and tap M4 holes for the included machine screws, and skip to
step 18.
10
If using the nut plates, starting in one corner of the template, place a nut
plate over the larger hole
® dealer.
The smaller hole
on the template.
11
If the smaller 3.6 mm (
the smaller hole on the template, mark the new location.
12
Repeat steps 10 and 11 for each nut plate.
9
13
Using a 3.6 mm ( /
64
14
Remove the template from the mounting surface.
15
Starting in one corner of the mounting location, place a nut plate
back of the mounting surface, lining up the large and small holes.
The raised portion of the nut plate should fit into the larger hole.
in.) drill bit, drill one or more of the holes inside the
9
/ in.) holes on the template.
32
in.) pilot holes for the included wood screws, and skip
in.) holes for the included nut plate and machine
drilled in step 9.
on the nut plate should line up with the smaller hole
9
/ in.) hole on the nut plate does not line up with
64
in.) drill bit, drill the smaller holes.
Printed in Taiwan
April 2020
190-02728-90_01
on the
