PARTS LIST
PART NO. DESCRIPTION
1 Front stabilizer
2 Front support pipe
3 Seat support pipe
4 Rear support pipe
5 Rear stabilizer
6 Backrest adjust pipe
7 Backrest Frames
8 Long pad tube

ADJUSTMENTS

26
19
22
26
32
26
1
continued
QTY PART NO. DESCRIPTION
1 9 Short pad tube
1 10 Long dumbbell hook
1 11 Short dumbbell hook
1 28 Wrench
1 29 Knob
1 30 Square plug
2 31 Globose plug
1 32 Oval plug
21
24
3
24
2
13
26
19
15
35
32
QTY
1
2
2
2
1
2
4
2
22
17 25
25 22
19
4
25
17
22
25
27
STEP 1
1. Attach the Connecting pipe cover (35) to the Front stabilizer
(1) then attach them to the Front support pipe (2) with 1 Hex
head bolt M8*80 (15) 4 Curve washer M8 (26) and 1 Nylon
locknut M8 (22) and 2 hex head bolt M8*30 (19).
2. Attach the Connecting pipe cover (35) to the Rear stabilizer
(5) then attach them to the Rear support pipe (4) with 1 Hex
head bolt M8*80(15) 4 Curve washer M8 (26) 1 Nylon locknut
M8 (22) and 2 hex head bolt M8*30 (19).
3. Attach the Seat support pipe (3) to the Front support pipe
(2) with 1 Hex head bolt M10*90 (13) and 1 L-bolt (27) and
please take note of that the L-bolt is in the top hole.
4. Attach the Seat support pipe (3) to the Rear support pipe
(4) with 3 Hex head bolt M8*20mm (17) 6 Flat washer M8
(25) and 3 Nylon locknut M8 (22)
NOTE: Make sure you fasten the bolts securely to avoid shaking and discomfort
when using the equipment.
PART NO. DESCRIPTION
33 Cushion pad
34 Cap
35 Connecting pipe over
36 Cover
37 Foam Pads
39 Backrest
40 Seat
41 10 Nylon bearing
34
26
5
35
15
26
19
QTY
1
2
2
2
4
1
1
2
