Summary of Contents for Panasonic WV-BWC4000
- Page 1 Important Information Body Worn Camera For professional use only WV-BWC4000 Model No. WV-BWC4000E Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. The model number is abbreviated in some descriptions in this manual.
-
Page 2: Table Of Contents
Contents Limitation of liability ........................8 Disclaimer of warranty ........................8 Preface ............................8 About notations ..........................9 About the user manuals ........................ 9 System requirements for a PC ...................... 9 Trademarks and registered trademarks..................9 Copyright ............................. 10 Open Source Software ........................ 10 Network security ......................... - Page 3 Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research. [WV-BWC4000] has been tested and found to comply with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines.
- Page 4 ISED radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the ISED radio frequency (RF) Exposure rules. • This [WV-BWC4000] has been tested and meets the ISED RF exposure rules when used with the compatible mount accessories supplied or designated for this product. Use of other accessories may not ensure compliance with ISED RF exposure rules.
- Page 5 <WV-BWC4000E> <For Europe> • Declaration of Conformity (DoC) “Hereby, Panasonic declares that the BWC (Body Worn Camera) is in compliance with the essential requirements and other relevant provisions of the Directive 2014/53/EU.” Hint: If you want to get a copy of the original DoC of our above mentioned products, please contact our web address: http://www.ptc.panasonic.eu...
- Page 6 ■ Safe Disposal of Lithium Ion/Polymer Battery Dispose of used Battery Pack according to local ordinances and/or regulations. Environment & recycling <WV-BWC4000> A lithium ion/polymer battery that is recyclable powers the product you have purchased. Please call 1-800-8-BATTERY for information on how to recycle this battery.
- Page 7 <WV-BWC4000E> Disposal of Old Equipment and Batteries Only for European Union and countries with recycling systems These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries must not be mixed with general household waste. For proper treatment, recovery and recycling of old products and used batteries, please take them to applicable collection points in accordance with your national legislation.
-
Page 8: Limitation Of Liability
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S). Disclaimer of warranty IN NO EVENT SHALL Panasonic i-PRO Sensing Solutions Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:... -
Page 9: About Notations
• The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. • All other trademarks identified herein are the property of their respective owners. -
Page 10: Copyright
Copyright Except for open source software licensed under GPL/LGPL and so on, distributing, copying, disas- sembling, reverse compiling and reverse engineering of the software provided with this product are all expressly prohibited. In addition, exporting any software provided with this product violating export laws is prohibited. -
Page 11: Security Alert When Using Wireless Lan Products
Security alert when using Wireless LAN products Wireless LAN provides with an advantage of freely connecting to the network as long as you are in the reach of radio waves. On the other hand, the radio wave reaches everywhere in the range regardless of obstacles such as walls. -
Page 12: Precautions
Precautions Turn off the power in air planes Periodic inspections shall be conducted. Failure to observe this may interfere with the Rust on the metal parts or screws may cause a safety of the flight. fall of the product resulting in injury or acci- dents. - Page 13 [Precautions for use] Do not touch the lens with your bare hands. To keep on using with stable performance A dirty lens causes deterioration of picture Do not use this product in hot and humid con- quality. In case of adhesion any dirt or other ditions for a long time.
- Page 14 About the CMOS image sensor AVC Patent Portfolio License • When continuously shooting a bright light THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE source such as a spotlight, the color filter PERSONAL USE OF A CONSUMER OR of the CMOS image sensor may become OTHER USES IN WHICH IT DOES NOT deteriorated and this may cause discolor-...
-
Page 15: Precautions For Installation
Precautions for installation Panasonic i-PRO Sensing Solutions Co., Ltd. assumes no responsibility for injuries or property damage resulting from failures arising out of improper installation or operation inconsistent with this documentation. For information about the installation tasks, refer to Installation Guide on our support web site. -
Page 16: Parts And Functions
Parts and functions [3] Mute LED [1] LCD display [2] Rec. LED Lens [4] Display button (DISP.) Mic. x4 places [5] Audio mute button (MUTE) [6] Multi function button (FUNC) Battery release button Battery release (Both side) button (Both side) [7] Rec. - Page 17 [1] LCD display The operating condition of the camera or a remaining amount of the battery is displayed. The fol- lowing describes the display layout. Refer to page 20 for further information about details of the display. Pict area Message area [2] Rec.
- Page 18 Note: • If 6. SSID mark, and 7. Traffic mark are not set beforehand in BWC4000 Configuration Tool, they will be skipped without being displayed. • When the Display button is pressed first, the backlight will light. When the Display button is pressed again or more times after that, the above menus will be displayed and switched (tog- gled).
- Page 19 [10] Power SW Control power On/Off Power SW (Off) Power SW (On) [11] Battery Pack A part from the Battery Pack included in the product package, additional Battery Pack is available for replacement. It can be used as spare battery when the battery of the camera is in an insufficient charge state.
-
Page 20: Indicators
Indicators A B C D Upper part: Pict area Lower part: Message area * “STARTING” or “SHUTDOWN” will be displayed on the whole area of the LCD irrespective of the above areas at the time of startup and shutdown. The following are descriptions about the display content and about how to change the display content. - Page 21 E Battery Displays the remaining battery status. Full Empty 50 % 80 % 15 % Being used Being charged [2] Message area <How to use the Display button> A Change the LCD screen Press the Display button. → Lights the backlight of the LCD. (The backlight will light for 5 seconds.) First time Second time and later →...
- Page 22 <Error notification> When an error occurred, content of the error will be displayed in the message area and the back- light will also light. Example: No remaining capacity in the internal “! MEM FULL” is displayed memory: The battery is in an insufficient charge “! BATT LOW”...
- Page 23 <Maintenance information> To display maintenance information, hold down the Display button for 5 seconds when the “Time and date” screen (toggled menu) is being displayed. It is possible to display the following contents on the maintenance information display screen. Each time when the Display button is pressed, the display content will be switched.
-
Page 24: Specifications
Specifications ● Basic Power source: Rechargeable lithium ion battery: 2670 mAh or more * Battery can be charged using Multi-Dock Charger (WV-BWC40D8), or Single Dock Charger (WV-BWC40D1) Power consumption: DC 3.6 V Continuous operating time* : About 12 hours Full-charging term* About 4 hours (100 %) Operating environment: Ambient operating... - Page 25 ● Camera Image sensor: Approx. 1/3 type CMOS image sensor Effective pixels: Approx. 2.4 megapixels Scanning area: [16:9 mode] 5.28 mm (H)×2.97 mm (V) {7/32 inches (H) × 1/8 inches (V)} [4:3 mode] 4.40 mm (H)×3.30 mm (V) {3/16 inches (H) × 1/8 inches (V)} Scanning system: Progressive Minimum illumination:...
- Page 26 ● Others Wireless LAN Communication Standard: IEEE802.11 a/b/g/n/ac Access mode: Infrastructure mode Frequency Band(STA): BWC4000 2.4 GHz band 2412 MHz to 2462 MHz (1-11 ch) 5 GHz band 5280 MHz to 5320 MHz (56, 60, 62, 64 ch) 5500 MHz to 5580 MHz (100, 102, 104, 106, 108, 110, 112, 116 ch) 5660 MHz to 5720 MHz (132, 134, 136, 138, 140, 142, 144 ch) 5745 MHz to 5825 MHz (149, 151, 153, 155, 157, 159, 161, 165 ch) BWC4000E...
-
