- Page 1 AIS - SERIES Microbial Air Sampler Instruction 3, Hagavish st. Israel 58817 Tel: 972 3 5595252, Fax: 972 3 5594529 mrc@mrclab.com MRC. 5.18...
-
Page 2: Table Of Contents
Thank you for purchasing MRC Microbial air sampler, this manual will guide you through the proper use of this equipment, please keep it for future reference. Directory Equipment introduction ----------------------------------------------- 2 Application areas -------------------------------------------------2 iii. Working environment ----------------------------------------------2 The main features... -
Page 3: Equipment Introduction
Equipment introduction Thank you for purchasing and using AIS-SERIES type microbial air sampler, it represents the latest air floating microbial detection concept. AIS-SERIES type microbial air sampler is a high effective multi-nozzle inhaling style plankton sampler. It is based on isokinetic sampling design, sampling is accurate. -
Page 4: The Main Features
IV. The main features 1. Built-in English and Chinese operation interface, automatically control start time, sampling volume; 2. Large-capacity memory, can automatically record 2000 sample data (sampling location, sample volume, sample time, etc.); 3. Reliable air sampling design, sampling head with up to 589 impaction nozzles, so that air uniformly distributed on microbial culture medium in a Petri dish surface, reducing the dust and microorganism overlap, effectively reduce count error;... -
Page 6: Operating Instructions
VII. Operation instructions 1. Operation flow chart: Main interface Start Menu Select Select sampling location number Function Data query (maximum 99 numbers) Press Select or▲ Press Select or▲ or▼ button Press Select or▲ or▼ button or▼ button Set sampling volume, Inquire past delay time, sampling Select a saved... - Page 7 ⑴ Sample volume setting: Press “Select” button to adjust the cursor position, press the “up” and “down” button to adjust to the desired sample volume, press "Exit" to exit the settings, press "Menu" to enter the next parameter setting. ⑵ Sampling delay time setting: Press “up” and “down” button to adjust to the desired sampling delay time, press "Exit"...
- Page 8 Note: If you choose to delete the sample settings it will delete all the settings that have been set, please choose carefully. ⑹ Backlight delay time setting: In this state, press “up” and “down” button to adjust the backlight delay time which ranges from 0 to 256 seconds, adjusted in steps of 1 second.
-
Page 9: Maintenance And Precautions
press “up” and “down” button to change group number. The screen displays parameters settings (sample volume, sampling delay time and sampling location code) of the current group. Choose an appropriate group and press "Start" then the sampler begins to prepare sampling, meanwhile sampling delay time countdown starts, sampling pump will run (begin sampling) when the countdown finished. -
Page 10: Troubleshooting
IX. Troubleshooting Phenomenon Reason Measures 1. Plug in 8.4V DC adapter Switch on but no 1. Low Battery 2. Open the lower cover to place a new display 2. Fuse burnt fuse 1. Wire is broken inside The pump not work 1. - Page 11 Factory test report Temperature: Humidity: Series No.: 1. Appearance: 2. Function tests: 3. Battery performance check: 4. Parametric tests: Sampling Location Map Test point Average Item & Criteria Sampling 0.38m / s head wind Sampling ± 0.5S time error Measuring Φ75 ±...
