Summary of Contents for IUL HALOES CALIPER
- Page 1 CAT. No. 5000997 HALOES CALIPER USER´S GUIDE DOC. No. 997-05...
- Page 3 HALOES CALIPER INSTRUCTION MANUAL Copyright (C) 2016 IUL, S.A. All rights reserved. Doc. No. 997-05 Cat. No 5000997...
- Page 5 INDEX INTRODUCTION TECHNICAL SPECIFICATIONS INSTALLING AND STARTING UP THE INSTRUMENT OPERATION AND USE OF THE CONTROLS BEFORE NOTIFYING THE TECHNICAL SERVICE...
-
Page 6: Use Of The Manual
USE OF THE MANUAL All the letters in bold: A, B, C, etc. refers to the stages which must be carried out by the operator. All the numbers: 1, 2, 3, etc. refers to the main illustration on the back cover. The numbers or letters in boxes indicates the keys that should be pressed. -
Page 7: Front Part
FRONT PART Lamp tube Reset push button Display of length Screen for sampling Handle wheel Dish spring Spring screw... - Page 8 REAR PART Fixing lamp screw Main power switch ON/OFF 10 Cable for mains 11 Light adjustment...
- Page 9 WHAT IS THE HALOES CALIPER? The IUL Haloes Caliper works as a real caliper measuring distances with readability of 1mm but without touching the object to be calibrated. The operator must only center the Petri dish containing the samples in the illuminated field, rotating the handle wheel the size appears on the display.
-
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS Range of measurement: 35 mm Resolution: 0.1 mm Screen diameter: 55 mm Magnifying factor: 2.25 Zero position: Any point Counting direction: Up / Down Maximum turns rot. wheel: Working temperature: 5ºto 40ºC Power supply: 100~240V 50/60 Hz Dimensions: 270 x 230 x270 mm Weight: 4 kg... - Page 11 INSTALLING AND STARTING UP THE INSTRUMENT The Haloes Caliper should be received in perfect conditions. It has been fully tested at the factory and the packaging prevents possible troubles even if it has suffered roughest treatment. The instrument requires no special conditions for its installation. Its reduced size allows it to be located in any part of the laboratory.
- Page 12 OPERATION AND USE OF THE CONTROLS A. Turn the handle wheel, 5, counterclockwise, the top plate now is in the back position. WARNING: Never force the edges when you turn the handle wheel. B. Place the Petri dish touching the positioning spring in such a way that the spot to be measured just appears in the down part of the screen.
- Page 13 BEFORE NOTIFYING THE TECHNICAL SERVICE To change the lamp disconnect it, unscrew the tube cover and replace the old one. All the other mechanical and electronic parts must be served by the IUL official service in your country or to: IUL S.A.
- Page 15 IUL S.A. C/ Ciutat d’Asunción, 4 08030 Barcelona-Spain Phone +34 932740232 www.iul-inst.com...
