- Page 1 User Manual Splitter Arma DUO Double input DMX splitter / repeater SPAD-0-2D4D Version 2.01 June 22, 2018...
-
Page 2: Table Of Contents
Table of Contents Visual appearance Specifications Safe operation General information Installation LED indication Technical maintenance Connection scheme... -
Page 3: Visual Appearance
Visual Appearance Pic.1 Main interfaces and indicators 1 Protective lid 3 Power input 5 Status LED indicator 2 Device case 4 DMX IN/OUT ports Specifications Supported protocols DMX512, RDM, Modbus DMX input ports 1 or 2 isolated DMX output ports 4 or 5 isolated DMX connectors 15EDGVC terminal blocks... -
Page 4: Safe Operation
Whenever a fault is detected in the device, please contact the manufacturer. General information Splitter Arma DUO is a dual-channel device with 6 DMX input/output ports that operates as a regular splitter with 1 input and 5 outputs as well as two separated 1-to-2 splitters. -
Page 5: Installation
Installation Before mounting and power up, it is necessary to verify protective earthing and cable connectors. 1. Ensure the device has no damage due to transportation. 2. Remove device lid. If the device fixation is needed on a surface, wall, farm, attach the device housing to a surface, or install the appropriate fastening element. -
Page 6: Led Indication
5. All input and output channels have 120 Ohm terminators, managed by special DIP- switches TIN, T(1)–T(5). To connect the terminator to the line is necessary to set proper switcher in ON position, to disconnect- in OFF position. 6. Connect power supply terminal ~230 V. Some modifications of the device can be equipped with additional ground contact for terminal input power supply connected to the device. -
Page 7: Connection Scheme
Connection scheme OUT 1 DMX B (D mode) OUT 4 DMX À (S mode) OUT 2 DMX B (D mode) OUT 5 DMX À (S mode) IN DMX B (D mode) OUT 3 DMX À (S mode) OUT5 OUT4 POWER OUT3 ~100-250 VAC, 50/60 Hz... - Page 8 Please send all your warranty-related questions to support@sundrax.com All Sundrax products are covered by a 36 months warranty. Sundrax Electronics, 6008, First Central 200 2 Lakeside Drive, Park Royal, London NW10 7FQ United Kingdom + 44 (0) 208 991 33 19 office@sundrax.com...
