TECHNICAL SPECIFICATIONS:
Modello Ruote SL38C
10v Shimano / Sram (with
Cassette 1.80mm spacer)
Compatibility 11v Shimano
10-11v Campagnolo
Size
Rim Width
Height
Rim Tape 622x17mm
Tire
Clincher
Compatibility
Front
Hubs
Rear
Recommended
min 700x23 - max 700x32
Tires Sizes
Front
Rear Non
Spokes
Drive side
Rear Drive
side
Nipples 15mm ABS, aluminum
TIRES
ZERO2 wheels are designed to use clincher
tires with inner tubes only. Check tires and inner
tubes dimensions according to the rim technical
specifications included in this user's manual.
WARNING: Do not use tubular or tubeless tires with
this wheel. The use of non compatible tires with this
wheel can cause sudden and unexpected loss of
pressure, loss of control and tire failure resulting in
serious accident and injury for the user.
• Before the tire installation check that rim tape is
already installed in the right position inside the rim; if
not please install first the rim tape.
• Make sure the rim tape cover all the rim bed holes
along the entire circumference of the wheel.
• The valve hole on the rim tape has to be placed at
the same position of the valve hole of the rim wheel
(Fig. 1).
• Install the tire on the wheel and proceede with tire
inflation as per tire manufacturer recommandations.
Fig 1
Valve hole
WARNING: Never exceed the maximum inflation
pressure recommended by the wheels manufacturer
as indicated in this user's manual. Excessive tire
pressures could damage the rim structure resulting in
serious accident and injury for the user.
WARNING: Tire installation requires a specific
experience of the product, in case of doubts please
contact an official Deda Elementi dealer or a qualified
bicycle technician. During tire installation don't use
tools or tire lever that can fold, damage or fragilize
the rim edge. An incorrect tire installation can cause
serious accidents and injury for the user.
SPROCKETS INSTALLATION
Deda Elementi wheels are available with Shimano®
/ Sram® 10-11 speed cassette and Campagnolo®
10-11 speed cassette. Read and carefully follow the
installation instructions of the sprockets.
The rear wheel with Shimano® freehub body is
supplied with a 1.80mm aluminum spacer that is
intended to be used with Shimano® /Sram®
622x16C
speed cassette only . Please don't use 1.80mm spacer
with 11 speed cassette.
21.5mm
25.0mm
WARNING: Since specific tools and experience are
necessary for proper sprockets installation, in case of
doubts it is recommended that the product be installed
by an official Deda Elementi dealer or a qualified
bicycle technician. An incorrect sprockets installation
100mm
can cause serious accidents and injury for the user.
130mm
WARNING: Please make sure that wheel freehub
body be compatible with your sprockets cassette
before proceed with the assembly. Failure to insure
compatibility between wheel and sprockets cassette
284 mm; flat;
can cause malfunction of the bicycle drive train
straight pull
resulting in serious accident and injury for the user.
297 mm; flat;
straight pull
WHEELS INSTALLATION INSTRUCTIONS
284 mm; flat;
• Insert the quick release into hub so that the lever be
straight pull
• Install the front and rear wheel respectively into the
• Tighten the quick release nut untill is in contact with
• Close the quick release lever from the Open to the
WARNING: Since specific experience is necessary
for proper wheels installation, in case of doubts it is
recommended that the product be installed by an
official Deda Elementi dealer or a qualified bicycle
technician. An incorrect wheels installation can cause
serious accidents and injury for the user.
WARNING: While adjusting the closing force manually,
please make sure do not tighten or untighten the nut
Rim tape too much. A ½ turn of rotation can result in the non
closing of the wheel or excessive closing force of the
wheel. The improper adjusting of the wheel closing
can cause serious accidents and injury for the user.
Fig 3
• When the lever is closed, make sure it is completly
• Check before every ride the closing force of the
WARNING: After cleaning the bicycle or a ride in rain
conditions, please lubricate pivot and cam points in
order to prevent oxidation phenomenons that damage
the correct mechanism functioning of quick releases.
on the non drive side of the wheel and tighten the
quick release nut slightly on the opposite side of the
lever. (Note: front quick release is shorter than rear)
fork and frame drop-outs.
the fork or frame drop-outs.
Closed position; if necessary adjust the closing
force manually through the nut (tightening the force
increases, untightening the force decreases) (Fig. 2).
Fig 2
OK
closed (full travel) and do not allow the frame or fork
to inhibit the complete closing of the lever (Fig. 3).
wheel and correct mechanism functioning of quick
releases.
10
Closed
Open
NO!
