shopPOPdisplays 12831 Assembly Instructions

Clear Acrylic L Shape Barrier - 17.75"H
ASSEMBLY INSTRUCTIONS
PARTS LIST:
90 Degree
Connector
(2 pcs)
*NO TOOLS REQUIRED
*TWO PERSON ASSEMBLY RECOMMENDED
STEP 1:
Peel off the protective plastic film from both sides of Main Panel Upright & Side Panel Upright.
STEP 2:
Stand up the Side
Panel Upright and push one
of the 90 Degree Connectors
onto the front edge of the
Side Panel Upright.
STEP 5:
Make sure both of the 90 Degree Connectors are pushed in and fully engaged with each of
the panels, and the product is rested on a flat surface.
shopPOPdisplays makes no claim that these assembly instructions cover all details, conditions or variations, or that they cover all possible contingencies in connection with the assembly or installation of
this product. It is the Purchaser's responsibility to ensure that all components of this product are properly assembled and installed in accordance with these instructions. shopPOPdisplays assumes no
obligation or liability on account of any third-party recommendations, opinions or advice as to the assembly or installation of this product.
READ ALL INSTRUCTIONS BEFORE YOU BEGIN. DO NOT JUMP AHEAD OF ANY STEP.
Main Panel Upright
(1 pc)
STEP 3:
Push the other 90
Degree Connector onto the Side
Panel Upright, spacing it out to
the desired distance. Make sure
both 90 Degree Connectors are
facing the same direction.
ASSEMBLY COMPLETED
12841
INCLUDED WITH
ITEM 12842 ONLY:
Side Panel
Upright
(1 pc)
H-Connector
(1 pc)
STEP 4:
Push the 90 Degree
Connectors from the
assembled Side Panel Upright
onto one of the sides of the
Main Panel Upright.
NOTE: Make sure top edges of
Side Panel Upright and Main
Panel are flush with each other
USE SUPPLIED H-CONNECTOR TO
ATTACH OPEN ENDS OF MAIN
PANELS TOGETHER
12842
(Set of 2)
1 2
