ICT BASE STATION Series Instruction Manual

ICT BASE STATION SERIES

LIMITED WARRANTY

The ICT Base Station Series provides a sleek, mobile radio base station. These
covers are individually customized to fit various radio models. The ICT Base
ICT Ltd. warrants to the original consumer purchaser that this product shall be in good working
Station Series covers and ICT Comm Series power supplies may be purchased
order, free from defects in materials and workmanship, for a period of one (1) year from the date
separately or as a Complete Base Station (power supply assembled with cover).
of purchase. Should failure occur during the above stated time period, then ICT will, at its option,
repair or replace this product at no additional charge except as set forth below. All parts, whether
These instructions should be read before using the product and it should be
for repair or replacement, will be furnished on an exchange basis. All exchange pieces become
saved for future reference.
the property of ICT. This limited warranty shall not apply if the ICT product has been damaged by
unreasonable use, accident, negligence, disaster, service, or modification by anyone other than
the ICT factory.
Setup
Limited warranty service is obtained by delivering the product during the above stated one (1)
year warranty period to an authorized ICT dealer or ICT factory and providing proof of purchase

Remove power cord from unit before removing cover.
date. If this product is delivered by mail, you will insure the product or assume risk of loss or
CAUTION! HIGH VOLTAGE INSIDE!
damage in transit, and prepay shipping charges to the factory.
 Remove 4 screws and washers.
Every reasonable effort has been made to ensure that ICT product manuals and promotional
materials accurately describe ICT product specifications and capabilities at the time of
 Remove backing from foam tape (included) and apply it along the top of the
publication. However, because of ongoing improvements and updating of ICT products, ICT
power supply, flush with the front, as shown in diagram "A".
cannot guarantee the accuracy of printed materials after the date of publication and disclaims
liability for changes, errors or omissions.
 Install base station cover over power supply. Re-install 4 screws and
If this ICT product is not in good working order, as outlined in the above warranty, your sole washers, adding the 2 supplied star washers in the 2 rear cover holes only.
remedy shall be repair or replacement as provided above. In no event will ICT be liable for any
These washers should be between the 2 cover metals as shown in diagram
damages resulting from the use of or the inability to use the ICT product, even if an ICT employee
"B". This is required to maintain chassis ground on external metal
or an authorized ICT dealer has been advised of the possibility of such damages, or for any claim
components.
by any other party.
 Do not tighten cover screws until radio has been installed and adjusted.
ICT reserves the right to make changes without further notice to any products or documentation
for improvement of reliability, function, or design.
Notes
ICT Ltd. does not recommend use of its products in life support applications wherein a failure or
malfunction of the product may directly or indirectly threaten life or cause injury. The user of ICT
 ICT Base Station series use thread cutting screws. When reinserting, avoid
products, which are to be used in life support applications as described above, assumes all risks
tapping a second thread in hole.
of such use and indemnifies ICT against all damages.
 Cover VTX5 for Vertex radios also has a rubber grommet at both radio
mounting points. Do not over tighten.
INNOVATIVE CIRCUIT TECHNOLOGY LTD.
26921 GLOUCESTER WAY LANGLEY, BRITISH COLUMBIA, CANADA
T 604.856.6303 F 604.856.6365
V4W 3Y3
www.ict-power.com
SIGNED OFF BY:
DIAGRAM "A"
THEPOWEROFRELIABILITY
ICT BASE STATION SERIES
INSTRUCTION MANUAL
foam tape
DIAGRAM "B"
Rear 2 screws only
power supply
rear view
INNOVATIVE CIRCUIT TECHNOLOGY LTD.
855-022-002
base station cover
star washers
