- Page 1 MARCONI 50 PS RADIO RTW Radio tubular motor plug & play with manual adjustment option of the end limits, specific for: rolling shutters with rigid links and stoppers (not necessary when the motor is in manual setting mode). PROGRAMMING...
- Page 2 MARCONI 50 PS RADIO RTW LIMIT SWITCH AUTOMATIC PROGRAMMING Attention: the rolling shutter must be equipped with rigid links and stoppers Push the UP and DOWN buttons simultaneously and wait for the feedback Check rotating direction If the rotation direction is correct,...
- Page 3 MARCONI 50 PS RADIO RTW LIMIT SWITCH MANUAL PROGRAMMING Adhere to the procedure: start from the up limit switch Press the up and down buttons simultaneously - Feedback Check rotating direction If the rotation direction is correct, push the UP and DOWN buttons...
- Page 4 MARCONI 50 PS RADIO RTW LIMIT SWITCH MANUAL PROGRAMMING Adhere to the procedure: start from the up limit switch Record the up limit switch position and keep pressed, up to Feedback Reach the down limit switch position Record the down limit switch position...
- Page 5 MARCONI 50 PS RADIO RTW RESET Switch off the power supply and then restore MOTOR FEEDBACK NO MOTOR FEEDBACK THE MOTOR THE MOTOR IS NOT PROGRAMMED IS ALREADY PROGRAMMED Carry out the programming Cancel procedure programming: a) Switch off the...
- Page 6 MARCONI 50 PS RADIO RTW MODIFYING THE LIMIT SWITCHES 1. Carry out the reset procedure 2. Repeat programming ADDING A REMOTE CONTROL Remote control Remote control already programmed to be programmed Press for 2 sec Press for 0,5 sec Feedback...
