Acumen E Installation & Operation Instructions

Electric projection screen

Advertisement

Quick Links

Acumen
E & V - 220V
Electric projection screen

Overview - Components

Electrical Knock-outs
(Top and Back)
Motor Wiring
Access Panel
Read and understand all warnings
Contents
Overview - Components .......................................................................................1
PLEASE READ - Safety Information ....................................................................2
Section 1 - Electrical Connections .....................................................................2
Section 2 - Fascia Removal .................................................................................3
Section 4 - Operation............................................................................................3
Section 5 - Hanging Screen .................................................................................4
Removable Fascia
CAUTION
(Page 2 of this document)
..............3
Wall / Ceiling
Mounting
Brackets
before beginning installation.
Section 6 - Limit Adjustments .............................................................................6
Section 9 - Tab-Tension Adjustment Procedure ............................................10
Section 10 - Dimensions
(Tab-Tensioned Surface Shown)
- Wall & Ceiling Bracket Dimensions for Mounting
BACK PAGE
If you have any difficulties installing or servicing your
Draper, Inc. | 411 S. Pearl St. Spiceland, IN 47385
© 2021 All Rights Reserved
INSTRUCTIONS
INSTALLATION & OPERATION
TOOLS
REQUIRED
PENCIL
Extruded
Aluminum
POWER DRILL
Case
TAPE MEASURE
LEVEL
HARDWARE
HEX WRENCH
.................9
..........................11
Acumen, call your dealer or Draper, Inc.
draperinc.com | 765.987.7999 | 800.238.7999
|
FORM: Acumen_E_V_220V_Inst20
(by others)
/
"
3
32

Advertisement

Table of Contents
loading

Summary of Contents for Acumen E

  • Page 1: Table Of Contents

    BACK PAGE Section 5 - Hanging Screen .................4 If you have any difficulties installing or servicing your Acumen, call your dealer or Draper, Inc. Draper, Inc. | 411 S. Pearl St. Spiceland, IN 47385 draperinc.com | 765.987.7999 | 800.238.7999 FORM: Acumen_E_V_220V_Inst20...
  • Page 2: Please Read - Safety Information

    Important Safety Information Improper installation and use of the Acumen screen can result in serious injury or death. Primarily, injuries can occur if the unit falls due to imprecise installation, mishandling of the unit during installation, or installation on an insufficient wall or ceiling structure. Please use extreme care.
  • Page 3: Section 2 - Fascia Removal

    R o lle r dowel shipping brackets are removed Please Note: Before fully operating screen: lower viewing surface enough to fully S C R E E N expose shipping brackets, then remove shipping brackets See Fig. 2. D O W E L FRONT VIEW Remove ½”...
  • Page 4: Section 5 - Hanging Screen

    Installer must also ensure that structure is of adequate strength. W A L L M o u n t i n g H a r d w a r e N O T E : 2. Ensure that mounting brackets are level.
  • Page 5 Acumen E & V - 220V ™ page 5 of 12 Ceiling Bracket Assembly Section 5.3 - Ceiling Installation: 1. Attach Ceiling Brackets to Mounting Brackets using the provided hardware (see figure at right) ACUMEN 2. Secure the Ceiling Brackets to the ceiling using appropriate hardware...
  • Page 6: Section 6 - Limit Adjustments

    Acumen E & V - 220V ™ page 6 of 12 Section 6 - Limit Adjustments Figure 9 Section 6.1 - Standard Motors (Fig. 10) DOWN Limit DOWN Limit (I) Please Note: Screen limits Section 6.1.1 - "Down" Limit Adjustment (requires 5/32"...
  • Page 7 Acumen E & V - 220V ™ page 7 of 12 Section 6.2 - Limit Adjustments for Motors with Internal Low-Voltage Controllers (Fig. 12) Please Note: Hold STOP button for 3-5 seconds while in programming mode to reverse motor direction.
  • Page 8: Section 7 - Wiring Diagrams: 220V Motor And Quiet Motor

    220V, control systems. To 220V Line 50 Hz. * These wiring diagrams are for Acumen screens with motor on audience left , and fabric unrolling from the back of the roller (standard) (standard) ILT Data Cable Connection...
  • Page 9: Section 8 - Accessing Internal Low-Voltage Control Unit

    Acumen E & V - 220V ™ page 9 of 12 Section 8 - Accessing Internal Low-Voltage Control Unit (LVC-IV) PLEASE NOTE: Applies ONLY if Unit is built into case. 1. Using a 3/32" Hex Wrench, remove the screw from the wiring access door on the motor end of the case.
  • Page 10: Section 9 - Tab-Tension Adjustment Procedure

    Acumen E & V - 220V ™ page 10 of 12 Section 9 - Tab-Tension Adjustment Procedure END OF END OF DOWEL DOWEL Please Note: The Draper Tab-Tensioning System is factory-set, and under Figure 14 normal circumstances will not require field adjustment. If wrinkles are observed, however, follow the adjustment procedure shown in Figure 9.
  • Page 11 Acumen E & V - 220V ™ page 11 of 12 Section 10 - Dimensions (Tab-Tensioned Surface Shown) Case Length Varies 18" Max. 18" Max. Centered Ceiling Bracket (457mm) (457mm) ACUMEN " 181mm End of Case Dimensions - Shown with Ceiling Bracket "...
