A quick overview of the controls

CON FI GU RE switc h
This ch o os es th e or d er o f the
fou r in ter na l e ffec ts, a s s ho wn
b y th e LED s n ex t to th e
s witc h. S ee pa ge 3 2.
COMPRESS ( 1) is a s ing le -
k no b co m pr es s or /lim ite r.
Tur n le ft fo r les s
c om pr es s io n, to the righ t for
a totally co m pr es se d s ou n d.

Rear Panel

Plu g th e p owe r ad ap ter in
h er e.
The Mod Link co nnec tor s le t
y ou c on n ec t Mod FX b o xe s in
a c ha in , with ou t ha v in g to us e
inp ut a n d ou tpu t ca b le s
within the c h ain.
16
D ISTO RT (2 ) ad ds d istor tio n
a nd "cr u nc h" to the sign a l.
Tur n clo ck wis e fo r m or e
d is to rtion , c ou nter - cloc k wise
for les s .
BYPASS le ts s ign al pa ss
thr ou gh with o ut a ny effe c ts .
The FOO T SWI TCH ma y be
c on ne cte d to an y mo m en ta r y
p ed al, to en g ag e th e BYPASS
fun ctio n .
I NPUTS a nd O U TPUTS a re
s ta nd ar d 1 /4 " lin e- lev el
jac ks .
BITRN ESS MOD E s witc h
s elec ts on e o f th e s ix k ind s of
Bitrn es s e ffe cts, a s s ho wn by
the LED s n ex t to th e s witch .
D UAL PH ASO R
( 3) a djus ts th e
p ha so r' s s pe e d.
Tur n co u nter -
c lo ck wis e to tu rn
o ff.
BITRN ESS
c on tr ols d iffer en t
thing s, de pe n ding
o n th e m od e. S ee
p ag e 2 7.
Sig na l LED
Whe n th is lig hts gr e en , the
Bitrm an is g e ttin g a n in p ut
s ig na l. Whe n it' s r ed , it' s
s ee in g too m u ch lev e l...s o
tur n do wn th e ins tr u me nt...
...or th e TRI M co ntro l h er e
o n th e b ac k p an el.
I f yo u' r e us ing a Mo dLin k
c ha in , y ou o n ly n ee d to
c on ne ct to th e firs t u nit's
inp ut, a nd th e la st un it' s
o utpu t.
