Connections
Connecting to the Main Outputs of a mixing
console:
In addition to channel inserts, most mixing consoles have main
insert jacks near the main outputs. You can use insert cables to
connect the Philtre to the main L/R bus the same way you
connect it to a pair of channels. Simply connect one insert cable
to the left main insert of the mixer, and connect the two mono
jacks to the left INPUT and OUTPUT of the Philtre. Use another
insert cable to connect the right main insert to the right INPUT
and OUTPUT of the Philtre.
Alternatively, you could plug the mixing console's main outputs
directly into the Philtre's inputs, then feed the Philtre's outputs to
your monitor amps or mixdown recorder. However, with this
method if you fade down the volume at the end of the song, the
sound quality may change as you fade. That's why it's better to
use insert jacks, if they're available.
