TE590 Commissioning Instructions

Requirements

•

TE590

•

SIM Card

•

Small Philips Head Screwdriver

The device should be in its default factory state. If not please follow Internal TE590 Default Instructions process

SIM Insertion

1. Remove battery by lifting battery clasp

2. Remove SIM tray cover using small Philips screwdriver

3. Left is SIM right Micro SD Memory card

4. Slide SIM tray up to unlock and lift

5. Inset SIM card as per orientation shown on SIM tray

6. Lower SIM tray and slide SIM tray down to lock

7. Replace SIM tray cover placing hooks in first

8. Replace screw and tighten

9. Reattach battery

Initial Device Setup from Default

1. Press and hold down power button/channel knob until screen displays Telo Systems logo

2. With device display on swipe up from the bottom to unlock

3. Click Got It on welcome hint

4. Uninstall TeloPTT

a. Press and hold TeloPTT application icon

b. Drag and drop to the bin/uninstall icon (top centre)

c. Select OK when prompted

d. Message appears bottom centre confirming the uninstall

5. Set up Wi-Fi connection

a. Open Settings

b. Choose Wi-Fi

c. Toggle to On

d. Select available Wi-Fi network

e. Enter password when prompted

Click connect

g. Click back button

SIM Setup

1. From step 5.g. select More

a. Click Cellular networks

b. Turn Data Roaming On

c. Select preferred network type as 4G

d. Click Access Point Names/APN

Wireless Logic SIM

i. Click "+" icon

ii. Set name to "Wlapn.com"

iii. Set APM to "Wlapn.com

iv. Set Username/Password to Airsys

v. Click three dots icon and "Save"

Jola SIM

Click "+" icon

ii.

Set name to "globaldata.iot"

iii.

Set APN to "globaldata.iot"

iv.

Click three dots icon and "Save"
