- Page 1 High precision reduction gear TwinSpin G series ® OPER ATING MANUAL Edition I/2020...
- Page 2 ® Operating manual TwinSpin G series reducers 1. General information 1.1 Content of this manual • This manual contains important information about how to safely operate the TwinSpin G series reducers and properly ® assemble, maintain, and dispose of it. •...
-
Page 3: Safety Instructions
Product characteristics 2. Safety instructions 2.1 General • Only persons who have read and understand this manual may assembly, operate and maintain reducers. Further, the persons operating with reducers must have qualification required for working with this type of devices. •... - Page 4 ® Operating manual TwinSpin G series reducers 2.5 EU Directive 2006/42/EC Reducer is a mechanical component only. It is used in machines and systems. Therefore, it is not a machinery or a partly completed machinery within the meaning of the Directive 2006/42/EC of the European Parliament and of the Council. A declaration of conformity is not therefore necessary for reducers.
-
Page 5: Delivery Conditions
• product type and size • reduction ratio • model • serial number 3.3 Technical data and dimensions Basic parameters of reducer as torque and allowed speed together with outer dimensions can be found • in our catalogue • at our web page www.spinea.com... -
Page 6: Storage And Transport
After 6 months it is necessary to preserve the reducer again. • Never stand under suspended load as this possess risk of injury. 3.6 Warranty The warranty is specified in the General Delivery Terms of SPINEA, s.r.o. For more information visit our website: www.spinea.com... -
Page 7: Assembly Preparations
Product characteristics 4. Assembly Instructions 4.1 Initial notes • To get the maximum performance from the reducer, it is important to pay attention to the installation, assembly accuracy, sealing and lubrication. Most motor adapter flanges are available on request, please contact the sales department or your local sales representative for further assistance. -
Page 8: Tightening Torque
® Operating manual TwinSpin G series reducers 4.4 Tightening torque • For the safe transmission of external loads applied to the reducers, it is required to use connecting screws of at least 10.9 grade and to degrease contact surfaces of friction joints before the installation. Tightening torques of screws are shown in the table below. - Page 9 Product characteristics 4.5.1 Mounting with a keyed motor shaft • Make sure that all bolt holes, screws and connecting adjacent surfaces are free of grease and dirt. • Assemble the motor flange to the input side of the Reducer, use prescribed tightening torques. •...
- Page 10 ® Operating manual TwinSpin G series reducers 4.5.2 Mounting with a spline connection • Make sure that all bolt holes, screws and connecting adjacent surfaces are free of grease and dirt. • Assemble the motor flange to the input side of the reducer, use prescribed tightening torques. •...
- Page 11 Product characteristics 4.5.3 Mounting with a coupling • Make sure that all bolt holes, screws and connecting adjacent surfaces are free of grease and dirt. • Assemble the coupling to the input shaft of the reducer. Tighten the bolts. When assembling coupling observe instructions provided by the coupling manufacturer.
- Page 12 ® Operating manual TwinSpin G series reducers 5. Operation of the reducer • Run the reducer only within its specified technical parameters. • Use reducer in clean and dry environment. • Operate the reducer within defined ambient temperature range -10°C to +40°C. Please contact manufacturer when operating conditions are outside of those limits.
- Page 14 SPINEA, s.r.o. Okrajová 33 080 05 Prešov Slovakia, EU ID No.: 31 687 580 Incorporated in Company Register of District Court Prešov, Section: Sro, File No.: 10314/P Tel: +421 51 770 01 56 E-mail: info@spinea.com Web: www.spinea.com...
