HiMirror Mini Premium X Quick Start Manual

PACKAGE CONTENTS

Power Adapter
HiMirror Mini Premium X

OVERVIEW

Camera Cover Button
High Performance Speaker
High Resolution Camera
13"
10.1"
Ambient Makeup Light
6
4
Micro USB Port x2
Touch Key
Back
Menu
Mirror / Light
High Sensitivity Microphone
Wireless Charging Pad
Serial Number
SN
• 13" mirror size with 10.1" TFT LCD touch panel (Rotatable)
Touch Key Functions
Back Back to previous page
Menu Bring up the menu
Mirror / Light Switch between Mirror mode and
ambient makeup light
2
4
Micro USB Port –
Connect with HiMirror
Mini Premium X supported
peripheral devices.
USB Port –
Connect with HiMirror Mini
Premium X supported
peripheral devices.
6
Rotatable Panel –
Rotate the panel counterclockwise for videos or supported apps.
Quick Start Guide
Quick Start Guide Warranty Card
2
Rotating Disk
7
Power Jack 1
1
3
Camera Cover Button –
Push to cover / uncover
the camera.
5
7
Wireless Charging Pad –
Place a supported mobile phone on the pad to recharge.
Cleaning Cloth Stylus
Slotted Screw 3
Retaining Ring
3
5
SD Card Slot
USB Port 4
Power Button
Power Jack –
Connect HiMirror Mini
Premium X to a power
outlet using the provided
power adapter.
Slotted Screw –
Rotate the slotted screw
clockwise with a coin to fasten
the hinge when it gets loose.
Retaining Ring –
Rotate the retaining ring
counterclockwise to unlock the
rod and adjust the height of the
panel, and rotate it clockwise to
lock again.
SD Card Slot –
For technical support and
customer service.
