Page 1 USER MANUAL PRESSURE SWITCHES AND TEMPERATURE SWITCHES Series www.georgin.com...
Page 2 User Manual - P series Introduction Purpose Operating principle Pressure Equipment Directive (PED) Qualified equipment in accordance with RCC-E General information concerning functions Before installation Storage Before installation III. DOs and DON'Ts General Recommendations Special recommendations Prohibited actions Advice IV. Commissioning Mounting the housing Mounting Adjustment Selection guide Equipment required...
Page 3: Operating Principle
User Manual - P series Introduction You have just acquired a GEORGIN instrument that has undergone extensive testing and several quality checks to ensure your complete satisfaction. Appropriate specification, according to your process, and compliance with the instructions in this manual will ensure an optimum working life for your instrument.
Page 4 User Manual - P series Qualified equipment in accordance with RCC-E The pressure switches and temperature switches of the P series meet the design and construction rules for electrical equipment of nuclear plants. Refer to the equipment identification sheet (according to the last index NTP N 100 – consult us) for a definition, installation rules and recommendations for maintenance of the equipment in accordance with the associated quality and general requirements.
Page 5: Before Installation
User Manual - P series For temperature switches, the minimum dead bands given in our manuals are recorded under ideal test conditions. The sensing element experiences the temperature variations of the installation without delay and in its bulk. In operation, these dead bands can be different in view of the exchange conditions: rate of temperature change, specific heat, radiation, inertia of the measuring instrument compared to inertia of temperature switch, presence of a sleeve or immersion sleeve, etc.
Page 6: General Recommendations
1.7. Vibrations Georgin recommend avoid mounting the instrument directly on vibrating equipment. Otherwise, an effective anti-vibration system, fully suitable for installation (assembly type, process connection, electrical connection, ...) and its environment, must be chosen.Flexible piping connections and silent blocks may sometimes be necessary.
Page 7: Special Recommendations
User Manual - P series 1.8. Mounting the housing (see Chapter IV.1) Georgin recommends mounting the housing in accordance with the following rules: a. For bellows or Bourdon tube pressure switches and temperature switches: The orientation of the housing has little effect on the operation of the instrument, but an upright (vertical) position is nevertheless recommended (with adjustment screw facing upwards).
Page 8: Prohibited Actions
User Manual - P series 2.4. Bourdon tube instruments (PL/PLB sensors) When the instrument is mounted on rigid fittings, ensure that the mount does not apply any residual loads to the process connector. 2.5. Temperature switches Any difference in level between the housing and the probe must be taken into account. Where necessary, to inhibit the effect of the height of the liquid column, the calibration values may need to be corrected (for more information, ask us).
Page 9: Mounting The Housing
(D)MABV - DMKBV: Use the two M10 threads provided under the sensing element. (D)MJBV - (D)MPB: Use the two M6 threads provided under the sensing element. We also provide special mounting brackets for the purpose. Ask Georgin for further information. www.georgin.com...
Page 10 User Manual - P series 2. Mounting Avoid mounting on a vibrating wall. This may result in a premature electrical malfunction. It is especially when approaching the changeover thresholds that our devices are particularly sensitive to certain vibration frequencies. If no other mounting is possible, we recommend the use of elastic suspensions for any use on a vibrating wall, especially in the case of a slow evolution of the pressure or temperature.
Page 11 User Manual - P series 2.2. Temperature switch mounting Observe the environmental and fluid-related conditions corresponding to the characteristics of the instruments. Never exceed the maximum temperature of the instrument indicated on the label on the side of the housing. A capillary introduced into the liquid can be of any length.
Page 12: Selection Guide
User Manual - P series Adjustment The adjustment procedures vary from one instrument to another. An instrument is adjusted according to several criteria. 1. Selection guide Dead Model Procedure Function Type of sensing element band adjustment Number Single Fixed Diaphragm differential...
Page 13: Equipment Required
User Manual - P series Clockwise: Increases the set point and/or dead band value. Anticlockwise: Lowers the set point and/or dead band value. Note: for RTPE type, the dead band adjustment screw VE is internal to the housing. 2. Equipment required »...
Page 14 4. Fine-tune the settings using adjustment screw VG (Lower and Upper threshold control). 5. Disconnect the instrument from the bench. 6. Apply a seal to adjustment screw VG using a Georgin seal kit (torque: 1.7 N∙m ±10%). 7. Close the cover and tighten the two captive screws (torque: 1.2 N∙m).
Page 15 7. Fine-tune the setting using adjustment screw VG (Lower and Upper threshold control). 8. Disconnect the instrument from the bench. 9. Apply a seal to adjustment screw VG using a Georgin seal kit (torque: 1.7 N∙m ±10%). 10. Close the cover and tighten the two captive screws (torque: 1.2 N∙m).
Page 16 10. Fine-tune the settings using screws VG (Low threshold control) and VE (High threshold control). 11. Disconnect the instrument from the bench. 12. Apply a seal to adjustment screws VG and VE using a Georgin seal kit (torque: 1.7 N∙m ±10%). 13. Close the cover and tighten the two captive screws (torque: 1.2 N∙m).
Page 17 13. Fine-tune the settings using the threshold adjustment screw (VG = Lower threshold and VE = Upper threshold). 14. Disconnect the instrument from the bench. 15. Apply a seal to adjustment screws VG and VE using a Georgin seal kit (torque: 1.7 N∙m) ±10%). 16. Close the cover and tighten the two captive screws (torque: 1.2 N∙m).
Page 18 9. Fine-tune the settings using screws VG (1st threshold, LP control) and VE (2nd threshold, HP control). 10. Disconnect the instrument from the bench. 11. Apply a seal to adjustment screws VG and VE using a Georgin seal kit (torque: 1.7 N∙m ±10%). 12. Close the cover and tighten the two captive screws (torque: 1.2 N∙m).
Page 19 13. Fine-tune the settings using the threshold adjustment screw (RG = 1st threshold and RE = 2nd threshold). 14. Disconnect the instrument from the bench. 15. Apply a seal to adjustment screws VG and VE using a Georgin seal kit (torque: 1.7 N∙m ±10%). 16. Close the cover and tighten the two captive screws (torque: 1.2 N∙m).
Page 20 User Manual - P series Wiring 1. The electrical switch Resting state of the switch(es) : At rest, contact is established between C-NC. Position above the threshold According to the type of action (opening or closing of the electrical circuit), make the electrical...
Page 21 IMPORTANT Intrinsic Safety certified instruments (Ex ia) are equipped with gold-plated contacts. These instruments must be interfaced via an Intrinsic Safety relay. Georgin recommends the RDN model - see fc-rdn-fren on www.georgin.com. The explosion proof switches with cable output must be imperatively connected to an approved terminal block and a junction box.
Page 22: Maintenance
» The mechanical working life of the sensing element » Frequency and conditions of operation of the instrument Georgin's standard* recommendation is to proceed as indicated: 1. Visual inspection of the instrument 1. Visual inspection (See Chapter II. Before installation) 2.
Page 23 GEORGIN guarantees the qualification of the equipment that leaves the factory. Any operation performed on the equipment other than adjusting the instrument releases GEORGIN from all liability in the event of failure. In the event you suspect a failure or permanent fault, return the equipment to our offices or our representatives, who are the only maintenance providers certified to perform expert assessments or repairs.
Page 24 GEORGIN Regulators France 14-16, rue Pierre Sémard - BP 107 - 92323 CHATILLON Cedex France Tel.: +33 (0)1 46 12 60 00 - Fax: +33 (0)1 47 35 93 98 - Email: regulateurs@georgin.com Belgium Temselaan 5 - 1 floor - 1853 STROMBEEK-BEVER Tel: +32 (0)2 735 54 75 - Fax: +32 (0)2 735 16 79 - Email: info@georgin.be...
