72V VDSL Adapter Unit
72V VDSL Adapter Unit
Product Manual
0713-SOM-00003-01
1
© Tritech International Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 72V VDSL and is the answer not in the manual?

Questions and answers

Summary of Contents for Tritech 72V VDSL

  • Page 1 72V VDSL Adapter Unit 72V VDSL Adapter Unit Product Manual 0713-SOM-00003-01 0713-SOM-00003-01 © Tritech International Ltd.
  • Page 2 The copyright in this document is the property of Tritech International Ltd. The document is supplied by Tritech International Ltd on the understanding that it may not be copied, used, or disclosed to others except as authorised in writing by Tritech International Ltd.

  • Page 3: Table Of Contents

    72V VDSL Adapter Unit Table of Contents Help & Support .................... 4 Warning Symbols ..................5 1. Introduction ....................6 2. Specification .................... 7 2.1. Dimensions ................... 7 2.2. Physical and Electrical Properties ..........8 3. Installation ....................9 3.1. Pin-Out Diagrams ............... 10 3.1.1.

  • Page 4: Help & Support

    Prior to contacting Tritech International Ltd please ensure that the following is available: 1. The Serial Numbers of the product and any Tritech International Ltd equipment connected directly or indirectly to it. 2. Software or firmware revision numbers. 3. A clear fault description.

  • Page 5: Warning Symbols

    72V VDSL Adapter Unit Warning Symbols Throughout this manual the following symbols may be used where applicable to denote any particular hazards or areas which should be given special attention: Note This symbol highlights anything which would be of particular interest to the reader or provides extra information outside of the current topic.

  • Page 6: Introduction

    72V VDSL Adapter Unit 1. Introduction The Tritech 72V VDSL Adapter Unit is designed to provide long length power and communications for the Tritech International Ltd range of Gemini products. The Adaptor Unit is powered from a standard Mains power supply and communicates to a control PC via Ethernet.

  • Page 7: Specification

    72V VDSL Adapter Unit 2. Specification 2.1. Dimensions 280.0 2° BOX DRAFT ANGLE 0713-SOM-00003-01 © Tritech International Ltd.

  • Page 8: Physical And Electrical Properties

    Specification 72V VDSL Adapter Unit 2.2. Physical and Electrical Properties Physical Properties Property Details Materials Enclosure: Aluminium alloy (AC-44300), Connectors: thermoplastic Finish Powder Coated Weights 2.93kg IP rating The Interface Box is sealed against dust and moisture ingress to IP64 standard Temperature range 5 to 40°C (-20 to 50°C in storage)

  • Page 9: Installation

    Before powering up, ensure that the mains socket being utilised has a proper connection to Earth. When connecting a Gemini and PC to the 72V VDSL Adapter follow the steps below. • Ensure that the Sonar Power switch button on the 72V VDSL Adapter is set to its OFF position •...

  • Page 10: Pin-Out Diagrams

    AC Live AC Neutral AC Earth 3.2. Fitting the UTC6JC18RJN25 connector In order to maintain the IP rating during use, the 72V VDSL Adapter Unit is supplied with the appropriate Souriau connector for mating onto the Ethernet port. 0713-SOM-00003-01 © Tritech International Ltd.

  • Page 11: An Example Setup

    Installation 72V VDSL Adapter Unit Remove the locking tab from the ethernet cable and Pass it through back shell of the Souriau connector. Push the front of the ethernet cable into the insert. Push the insert and cable into the front shell of the Souriau connector.

  • Page 12: Operation

    0685-SOM-00001; 0695- SOM-00006. The LEDs on top of the 72V VDSL Adapter help indicate the status of the unit as well as the state of communications to the attached Gemini unit. When the unit is first powered on, the Power LED will illuminate.
  • Page 13 The Ethernet Link and Ethernet Active LEDs will flash, indicating communication between the 72V VDSL Adapter and the PC The VDSL Link LED will illuminate and during both the initial negotiation of the VDSL link and the subsequent acquisition of data.

  • Page 14: Maintenance

    AC and DC supplies. 5.1. After using the unit Make sure that after using the 72V VDSL Adapter the unit does not have any obvious signs of damage. Particular attention should be taken with the cable connections on the unit in order to ensure that none of the connectors have broken, or bent, pins.

  • Page 15: If Storing The Unit For Extended Periods

    Maintenance 72V VDSL Adapter Unit Using a flat bladed screwdriver, rotate the fuse carrier anti-clockwise Remove the fuse carrier and visually inspect the fuse Using a multimeter, check the continuity of the fuse To refit the fuse, simply the reverse the process detailed above.

  • Page 16: Troubleshooting

    Contact Tritech International Ltd for more support if you suspect this unit being faulty. VDSL Link LED not illuminating Check that the cabling between the Gemini Sonar and the 72V VDSL Adapter is secure and properly fitted at both ends. All LEDs are illuminating, but no communication to the Gemini Sonar Check that the IP address of the Gemini and computer are compatible.

  • Page 17: Glossary

    A family of computer networking technologies for local area networks (LANs). Gemini Unless specified this can refer to any of the multibeam sonars in the Gemini range by Tritech International Ltd such as the Gemini Imager (720id), Narrow Beam Imager or Gemini Profiler (620pd). Light Emitting Diode...
