CONTACT
For in-depth manuals, datasheets and
other documents, please visit:
www.intercoax-emea.com
For Technical Support, please contact:
support@intercoax-emea.com
For other inquiries, please contact:
info@intercoax-emea.com
INTERCOAX EMEA NV
Krijtestraat 45A
9041, Ghent
Belgium
www.intercoax-emea.com
HARDWARE (RX)
LED Indicators
Indicator
Color
BNC Join
PWR
LINK
Quality
PWR
Data
PoE
DC OUT
www.intercoax-emea.com
Function
EoC Devices connected
56VDC input connected
Good data connection
Poor data connection
Good power supply condition
Additional adapter required
Flashes when data is transferred
PoE power supply status
DC OUT switch is ON
EUP-2704R-4T-PKG
QUICK INSTALL GUIDE
www.intercoax-emea.com
HARDWARE (TX)
LED Indicators
Indicator
Color
BNC Join
PWR
LINK
Quality
PWR
Data
PoE
DC OUT
www.intercoax-emea.com
Function
EoC Devices connected
56VDC input connected
Good data connection
Poor data connection
Good power supply condition
Additional adapter required
Flashes when data is transferred
PoE power supply status
DC OUT switch is ON
