FirstStudio
B
A
D
Figure 1
Figure 2
Figure 4
Figure 6
Figure 8
For detailed specifications,
product tutorial videos
Portrait Kit Instruction Sheet • Item: 870283 (
®
C
E
Figure 3
Figure 5
Figure 7
Figure 9
and more, please visit www.photoflex
FirstStudio Portrait Kit
The FirstStudio Portrait Kit is an exceptional lighting solution, which
features a two-light setup for creating traditional portrait lighting. The
FirstStudio Portrait Kit features FirstStar light heads, 250 watt halogen
lamps, Compact LiteStands and 45 inch adjustable silver-lined
umbrellas. Lightweight and easy to set up for capturing memorable
moments in portraiture.
This kit includes:
Figure 1
A. (2) FirstStar Lamp Heads
B. (2) 250 Watt Bulbs
C. (2) Adjustable Swivel
D. (2) 6.5' Compact LiteStands
E. (2) 45" Silver Umbrellas
A quick word about SAFTEY:
The high wattage bulbs in the FirstStar will burn hands when they are hot,
so please keep children away from lamps. When you leave the room, be
sure to turn off the lamps. Always disconnect power supply when changing
Replacing the Lamps
The First Star lamps give approximately 800 hours of use, but a spare is a
good idea. Bulbs can be replaced when cool, the same way a household
bulb is changed. The inner tungsten halogen lamp is protected by a shatter
resistant Pyrex
outer shell, so no worries about the oil in your hands
®
causing blistering or otherwise damaging the bulb. For replacment bulbs
use the 250 watt bulb (SKU # DP-250B). Other bulbs may be used, as long
as they do not exceed 250 watts.
Connecting the FirstStar Lamphead to Your Swivel
1. First loosen the securing knob on the swivel. Figure 2
2. Line up the Swivel with the yoke of the lamphead and slide into center
position. Figure 3
3. Once you have the lamphead in position, tighten securing knob. Figure 4
Setting up Your LiteStands
4. Loosen the securing knob on the brace collar. Figure 5
5. Slide the brace collar down as you pull out the legs. Figure 6
6. Secure the brace collar. Figure 7
7. To adjust the height of the LiteStand, loosen a knob below the
section you wish to lift and pull the section up to the desired
height; then tighten the knob to secure the section.
Figures 8, 9 and 10
®
.com
DP-FSPTKT)
the lamps.
Rev 8/2016
