Intex Pure Spa Owner's Manual

READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT
• Assembly and disassembly by adults only. This product is not a toy.
• This is not a flotation device.
• Not a step – Never allow anyone to stand or jump on the product.
• Never dive into a body of water from this product.
• Do not fill with water.
• To be used only as a bench with Intex Spa. Do not use for any other purpose.
• Follow the assembly instructions and ensure the bench flap is secured under the spa tub.
• Maximum load capacity: 440 Lbs (200 kg).
• When exposed to sun check product for hot surfaces before use.
• Do not expose the spa bench under direct sunshine.
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY, PARALYSIS OR DEATH.
SETUP INSTRUCTIONS
1. For correct installation of the bench to the spa tub, ensure the spa tub is empty of water first. See Fig 1.
2. Unscrew the air valve cap, insert the inflation hose into the air valve and inflate the bench to desired firmness. Do not over
inflate or use high pressure air compressor to inflate. Ensure the air valve cap is securely closed after inflation.
3. Place the inflated bench on the selected area and make sure the spa tub is sitting over the bench flap. Ensure the bench
flap is between the spa tub and the insulation ground cloth. See Fig 2.
4. The bench has two straps and each strap ending splits into a male and female buckle. Move the bench around so that
each strap on the bench is aligned with a strap on the external spa wall. NOTE: Once the spa tub is filled with water the
spa bench or tub cannot be moved!
5. Buckle one end of the bench strap to the spa wall strap buckle, and pull the strap tight. See Fig 3.1 & 3.2. Repeat with the
other bench strap.
6. Start filling the spa tub with water. Periodically check the bench is resting against the spa wall while filling with water. See
Fig 4.
1
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
When installing the bench, if the spa tub has been setup and filled with water, you must drain out the water first. The
water pressure will expand the spa tub wall outward, making the installation difficult.
ATTACHING THE SPA COVER TO THE BENCH
1. When the spa is no in use, place the spa cover over the spa tub, and secure two of the spa cover straps to the bench
straps. Fasten the remaining spa cover buckles to the respective buckles on the spa wall.
2. Ensure the buckles are securely fastened and locked.
3. Pull the buckled straps tight.
MAINTENANCE AND STORAGE INSTRUCTIONS
1. For cleaning use only mild soapy solution and water. Do not use any chemicals.
2. Open the air valve cap, push the stem in and turn 90 degree right to secure it in the down position.
3. Once the deflation is completed, push the stem in and turn 90 degree left to return it to the inflation position. Replace the
cap back.
4. Clean and air dry thoroughly before folding.
5. Lay the bench flat, fold loosely and avoid sharp bends, corners and creases which can damage the bench.
6. The original packaging can be used for storage. Store in a dry, cool storage location.
7. In case of repairs, use only common PVC repair glue and patches.
SAVE THESE INSTRUCTIONS
INTEX ® OWNER'S MANUAL
SPA INFLATABLE BENCH
WARNING
2
IMPORTANT
(271) SPA INFLATABLE BENCH ENGLISH 7.5" X 10.3" 03/25/2017
3.1 3.2
271
4
271-***-R0-1803
