- Page 1 BTA Bottle mount assembly instructions...
- Page 2 Parts list M5 Flat Washers M5 16mm Caphead (x2) screws (x2) M5 Nylock nuts (x2) M5 10mm Flanged *Already installed into the bottle Button screws (x4) mount M5 Square nuts D2Z BTA Bottle mount (x4) (x1) *Already installed into the bottle mount...
- Page 3 Part Name Dimension A (outside to Dimension B (Front width Dimension C (width of BTA θ D (°) between pad outside armrest width) for reference) mount for reference) and mount D2Z-BTA-0001 230mm 216mm 20mm D2Z-BTA-0003 240mm 224mm 30mm 0.75 D2Z-BTA-0005...
- Page 4 Step 1: Drill holes in the relevant positions on armrest (6mm drill bit) To align the holes perfectly, place armrest in the desired position on the bottle mount and mark holes as seen below We suggest that you take off the armrests from the cockpit if they are already installed in order to drill accurately...
- Page 5 Step 2: Insert M5 flanged screws into armrests...
- Page 6 Step 3: Place bottle cage on top by aligning the holes of the cage with the holes in the mount...
- Page 7 Step 4: Place washers and M5 16mm Caphead screws into the top holes to secure cage...
- Page 8 Step 5: Tighten all screws...
- Page 9 Step 6: Insert bottle...
- Page 10 Drag2Zero Limited Silverstone Sports Engineering Hub Unit 1129 Silverstone Park, Buckingham Road Silverstone, Northamptonshire, NN12 8FU, UK Follow us on Twitter, Facebook, Instagram @drag2zero Tel: +44 (0)1295 236117 Email: info@drag2zero.com © Drag2Zero Limited 2020...
