SoundOn WHP-210 Quick Start Manual

SoundOn WHP-210
Wireless Headphone
Noise-resistant Digital Wireless Technology
Patented Dual-Speaker Design in Each Ear-cup
Superior Sound Quality and Extended Bass
Wireless Transmitter Key Adapts To Every Music Player
Re-chargable Headphones Provide up tp 12 Hours Use
Unique Comfortable Headband Design
4

Specification

Model WHP-210
Wireless Technology
WiStereo TM for advanced 2-way digital
transmission in the 2.4 GHz frequency
band
Headphone Listen Time
Up to 12 hours (per charge)
Transmitter Usage Time
Up to 4 hours
Standby Time
Up to 3 months
Charge Time (full charge)
Up to 3.5 hours
Distance of Use 100 feet
H eadphone Weight
7.9 ounces
Transmitter Weight
1.6 ounces
Charging Method
AC Power Adapter
Headphone Battery Type
Lithium Polymer
Frequency Response 20Hz ~30,000Hz (perfect for all
music, game, and voice)
Audio Quality
Uncompressed audio for music
(CD-quality) and voice (extra clarity)
Distortion (T.H.D.)
<0.08% (professional grade audio
performance)
Speaker Drivers
2 on each side for full-range audio and
sub-woofer enhancement with SafeBass
technology
30mm Neodymium for left/right channels
40mm Neodymium for subwoofer
Headphones Made In China
1
Product Introduction
and Safety Approvals
The SoundOn WHP-210 is a high performance wireless
headphone delivering ultra clear sound with extended bass
effects. The headphone comes with a wireless music
transmitter that can be connected to any type of audio
source via a standard 3.5 mm audio jack. Also included is a
RCA cable with 3.5 mm adapter that can be used to
accommodate a separate 2-channel audio output port. The
transmitter can be powered by a power adapter, or by 3 AAA
batteries. You may find the battery cabinet located at the
bottom of the transmitter. The headphone has a built-in
Li-Polymer battery. When fully charged the battery offers up
to 12 hours of usage. To charge the headphone simply plug
into the power adapter. Please read the following certification
and safety approvals.
FCC Statement
Both the headphone and the trarnsmitter are compliant with
part 15 of the FCC rules. Operation is subject to the following
two conditions: (1)These devices may not cause harmful
interference, and (2)These devices must accept any
interference received, including interference that may cause
undesired operation.
CE
This product is CE marked according to the provisions
1.0
of the R&TTE Directive. (99/5/EC)
5

Parts Introduction

0
90
1
2
3
LED Indicator
7
4
Pair
3
5 Power On/Off
1
4
R 6 Charging Port
2
7 Reset
5
6
2

Unique Features

Based on advanced WiStereo
technology for reliable transmission of music in
the 2.4 GHz band.
Effective within 100 feet range from source.
Patented dual-speakers in each of the ear-cups
delivering a full range of sounds as well as a
soft, deep bass.
The transmitter can be powered by the power
adapter, or by 3 AAA batteries making it perfect
for on-the-go lifestyles.
Connects to any type of music input via a
standard stereo jack, such as iPod, Zune
player, DVD players, TV audio out, CD players,
etc.
Fast working, easy to use, automatic Pair
function.
Extended battery life lasts up to 12 hours when
fully charged.
Ultra comfortable headband design for long
wear hours.
6
1
Press to increase the headphone volume.
Length
2
adjustment
Press to decrease the headphone volume.
3 LED Indicator
0
90
A red indicator represents charging functions.
A green indicator represents signal connections.
Pair
4
Press "pair" button to connect the
wireless headphone and the USB Puck.
Power On/Off
5
Press this button to control power on/off.
6 Charging Port
Connect to the AC power adapter for charging.
Reset
7
If headphone is functioning improperly, poke
the reset hole by a paper clip.
3

Product Accessories

TM
digital wireless
Wireless Headphone * 1pc
AAA Batteries * 3pcs
User Guide * 1pc
7

User Guide Symbols

Steady red light
The headphone is charging
Steady greed light
Devices are paired
Flashing green light
Devices are waiting for pairing
Devices are not paired
Wireless Transmitter * 1pc
AC Power Adapter * 1pc
3.5mm Stereo Cable * 1pc
RCA Plugs with 3.5mm
Adapter* 1pc
