Instruction / PT230
Assemble the Soldering Head
1.1
Screw the spring loaded tip adapter to the soldering iron
clockwise, then the soldering head can be moved forward and
backward.
Make sure the exhaust vent is upward to avoid the damage of
tabletop.
1.2
Dissemble the Soldering tip by screwing the spring loaded tip
adapter counterclockwise.
1.3
You may install various tips for different operations.
1.4
CAUTION: When assemble the parts, be aware of burning by the
soldering iron.
Ignition
2.1
Move the ON/OFF switch to the ON position to release the gas.
2.2
Push the spring loaded adapter upwards to expose the burner head.
Then light the gas with an open flame (e.g. lighter or match) by
applying the flame to the ignition vent of the soldering tip.
3.1
Release the adapter then the flame will disappear inside the metal
sleeves. However, the soldering head which gas keeps flowing
through will generate heat.
