DCC Control Centre
Operating Instructions
Welcome
Thank you for purchasing a Bachmann E-Z C
DCC Control Centre. In the following pages we will explain
OMMAND
how to get the best from your E-Z C
OMMAND
DCC Control Centre so that you can enjoy the total freedom of
running your model railway using Digital Command Control (DCC).
1. Contents
• E-Z C
OMMAND
DCC Control Centre Unit
• Mains Plug Power Transformer
• Track Power Clip
• Connector Lead for Power Clip
• Connector Lead with Plain End (for use with alternative track wiring methods)
• Spare Address Labels
2. E-Z Command Control Centre - The Unit
fig.1
Locomotive Address
Function Button
& Function Buttons
Direction Button
(Lights indicate current selection)
(Lights indicate current direction)
Stop Button
Power LED
Speed Dial
X-Bus Socket
Track Connector
Mains Plug
Lead Socket
Transformer Socket
(Accessory Socket)
1
36501 Instruction Sheet
