Summary of Contents for Triad DamSurge Valve
- Page 1 amSurge Valve Flood Irrigation Operator Manual www.damsurgevalve.com...
- Page 2 ASSEMBLING THE SYSTEM .................PAGE 2 MAIN STATUS SCREEN ..................PAGE 3 BASIC PROGRAMMING ..................PAGE 6 PROFESSIONAL PROGRAMMING ..............PAGE 8 PRO-ELITE PROGRAMMING ................ PAGE 11 WARRANTY ....................... PAGE 13...
- Page 3 The SurgeSmart Controller The SurgeSmart Controller can be mounted using the provided hardware. Your unit will include (4) 1/4”-20 X 3/4” screws. The On/Off switch is located on the bottom of the unit, directly below the touchscreen. In order ( 1 ) to conserve battery power when the unit is not in use, the switch must be moved to the “Off”...
-
Page 4: Main Status Screen
Main Status Screen On the Main Status Screen you are able to see the status of currently running programs. At the top of the screen there are 2 arrows to indicate what direction the water is currently flowing. If the water is flowing right, the top right “Flow Direction” arrow will be green. If the water is flowing left, the top left “Flow Direction”... - Page 5 Main Status Screen The “Press to Start” button activates the programs and/or times entered into the “Basic”, “Professional” “Pro Elite” settings. The “Left Jog” and “Right Jog” arrows are used to manually turn the butterfly from left to right. To change the display language from English or Spanish, simply press and hold the button in the bottom left corner until the menu appearance changes to the desired language.
-
Page 6: Programming Your System
Programming Your System 3 LEVELS OF PROGRAMMING OPTIONS BASIC PAGE Basic allows you to select the right and left side of your field and manually enter the amount of time you wish to water each side. Enter the number of minutes you want in the “Left Flow” and “Right Flow”... - Page 7 Programming Your System Select the red “Enter” button between the two boxes once you have entered the time for each side. When you finish imputing your preferred settings, select the “Back” button to return to the main status screen then select the “Press to Start” button.
- Page 8 Programming Your System PROFESSIONAL PAGE Professional allows you to select individual Surge and Soak programs based on individual field requirements. Enter the desired program number from the charts on the next page into the “Surge Program” and “Soak Program” fields. You may also enter the percentages for the left and right flows.
- Page 9 Programming Your System PROFESSIONAL PAGE The system will automatically calculate and adjust the times for each side based on the Surge and Soak programs selected and the left and right flow percentages entered. The programs will start on the right side as default. If you wish to start on the left side, select the “Left Start”...
- Page 10 Programming Your System PROFESSIONAL PAGE The following charts list the times for each program. The times listed are in hours and minutes (hh:mm, 1:18 = 1hr and 18min). The program numbers to be entered in the “Surge Program and “Soak Program” fields are highlighted in yellow.
- Page 11 Programming Your System PRO-ELITE PAGE The Pro Elite page allows you to input the computer aided design information from your Pipe Planner or PHAUCET design plan. Simply enter your desired time into the boxes labeled “Hours” and “Minutes”. You may also enter the percentages for the left and right flows. The default setting is 50% left and 50% right.
- Page 12 Once you have entered your preferences press the “Enter” button in the center of the screen. Then press the “Back” button at the bottom of the screen. When you return to the Main Status Screen, select the “Press to Start” button. Thank you for purchasing the DamSurge Valve from Triad Fastener L.P.
- Page 13 Limited Warranty. Triad Fastener, L.P. (hereafter referred to as The Company) warrants that at the time of shipment the product manufactured by it shall be free from defects in material and workmanship in normal conditions of use and service. The Company’s warranty is conditioned upon the product being properly installed and maintained and operated within the product’s capacity under proper operating condition.
