Page 1 Extreme Cold Chain Solu2on (EU 868MHz) Q U I C K S T A R T E R G U I D E R E V I S I O N 1 . 0 N O V E M B E R 2 0 1 7 All rights reserved, reproduc2on rights are reserved and strictly limited, this document cannot be copied, redistributed or modiﬁed without Ac2lity or device manufacturer authoriza2on.
Page 2: Table Of Contents
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 INDEX INTRODUCTION .............................. 3 PRODUCTS ................................ 3 GATEWAY ................................ 3 PRODUCT OVERVIEW ............................... 3 CONTENT OF THE BOX .............................. 3 PREPARING THE INSTALLATION ..........................4 INSTALLATION ................................4 3.4.1 Wall Mount ................................4 3.4.2 Pole Mount ................................5 3.4.3 Metallic strapping Mount ............................ 5 3.4.4 Surge Installa:on ..............................6 3.4.5 Antenna Installa:on ............................. 7 CABLING AND POWER SETUP ........................... 7 CONNECTION TO INTERNET ............................. 7 DEVICE ................................ 8 CONTENT OF THE DEVICE BOX ..........................8 DEVICE OVERVIEW ..............................8 INSTALLING BATTERIES AND ANTENNA ........................9 DEVICE INSTALLATION .............................. 9 DEFAULT DEVICE CONFIGURATION .
Page 3: Introduction
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 1. INTRODUCTION Thank you for purchasing this “Click & Go Extreme Cold chain monitoring package”. The aim of this package is to monitor the temperature of your assets exposed to extreme temperature or diﬃcult radio environment. This package does not require any conﬁgura2on. The hardware is fully conﬁgured and ac2vated on the ThingPark Wireless network. Therefore, you only need to install the hardware on your premises, connect the gateway to the internet and start monitoring your assets. Easy! All soaware and tools are available with your ThingPark Store creden2als. We use the Single Sign On to provide the best experience.
Page 4: Preparing The Installation
Manual NICOLAS Long Range IoT Station Date ..... 08/04/2015 5.2 Mechanical implementation The LoRa IoT Station is based on a high impact resistant polycarbonate wall mounting cabinet that withstand harsh industrial and outdoor environments. It offers excellent flammability rating, good UV resistance and also good chemical resistance. Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 The dimensions are 231 mm x 125 mm x 60 mm.
Page 5: Pole Mount
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 Figure 14 : Universal antenna support dimensions 3.4.2 Pole Mount 6.3.3 Pole mounting by U-bolt By default, the LoRa IoT Station is delivered with a U-bolt to be mounted on a pole of a maximum diameter of By default, the LoRa IoT Station is delivered with a U-bolt to be mounted on a pole of a maximum diameter 60mm.  T o fix the U-bolt, it is recommended to use nuts provided in the mounting kit. of 60mm.
Page 6: Surge Installa:on
Reference:INSTALL_Lo Reference:INSTALL_Long_Ran Station Installation and Station Version ..1.0 Installation and Maintenance Version ..1.0 Author ..Lénaïc LO Maintenance Manual Author ..Lénaïc LOUVEL NICOLAS Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 Manual Long Range IoT Station NICOLAS Date ..... 08/04/20 Long Range IoT Station Date .....
Page 7: Antenna Installa:on
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 Figure 21 : Technical antenna specifications 3.4.5 Antenna Installation First, ﬁx the universal antenna support on the enclosure support using provided screw and nut. Next, ﬁx the First, fix the universal antenna support on the enclosure support using provided screw and nut. antenna on the moun2ng set: Next, fix the antenna on the mounting set: Universal antenna support mounting screw and nut Figure 22 : attachment of the antenna on the mounting set Once the RF antenna is ﬁxed, connect the N connector of the antenna cable on the connector based on the bokom of the casing as described on the ﬁgure below.
Page 8: Device
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 Note: default conﬁgura2on is: - IP Backhaul: Ethernet Only - Gateway needs a DHCP server with dynamic address capability - Ports 21,22 and 2404 need to be open on your ﬁrewall 4. DEVICE 4.1 CONTENT OF THE DEVICE BOX The Device Box contains 2 Sensing Lab THY- devices. 4.2 DEVICE OVERVIEW This Senlab T is a smart LoRaWAN™ sensor with a high precision temperature sensor, at ±0.2ºC accuracy. The ruggedized and IP68 design mean this Senlab T is well suited for con2nuous temperature monitoring in harsh environment. Sensing Lab TEM-LAB-14-NS...
Page 9: Installing Batteries And Antenna
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 4.3 INSTALLING BATTERIES AND ANTENNA The bakery and antenna are integrated in the device, so no manual opera2ons is needed 4.4 DEVICE INSTALLATION The SensingLab TEM-LAB-14-NS can be mount on wall using screw or tap. 4.5 DEFAULT DEVICE CONFIGURATION The device comes fully conﬁgured and ac2vated. Therefore, you do not need to send any Device Key Activation of the device informa2on to your ThingPark Wireless account. It is conﬁgured in Over The Air Ac2va2on mode (OTAA). The device is aiming to send a message every 10mn. To activate the Senlab device, you have to use a magnet (min pulling force 1Kg).
Page 10: Thingpark Wireless Portal
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 5. THINGPARK WIRELESS PORTAL Your ThingPark Wireless applica2on is accessible through the following URL: hkps://iot.thingpark.com/portal/web/ Once you log in, you will be able to see all the applica2ons that you have subscribed to via your package(s). Every package comes with the basic default tools provided by Ac2lity. Device Manager Wireless Logger Network Manager Each purchased package comes with a diﬀerent applica2on, which will be provided either by Ac2lity or by Wmw- Hub.
Page 11: Main Portal Description
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 5.1 MAIN PORTAL DESCRIPTION When you click on the wheels you see the following informa2on: Account informa2on: name, surname, address, VAT number etc.. Applica2ons: the soaware applica2on linked with the oﬀer you have purchased and its ac2va2on state. Status could be “Ac2va2on in progress” or “Ac2vated”. Oﬀers: list of packages including all related applica2ons. End Users: list of all users of the subscriber account. You can add other users here.
Page 12: Application Description
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 5.2 APPLICATION DESCRIPTION 5.2.1 Network Manager: The ThingPark Network Manager is a standard ThingPark applica2on which enables ThingPark Wireless subscribers to self-provisioning and manages the base sta2ons (LRRs). The Network Manager also enables the provisioning of a Base Sta2on posi2oning loca2on, without a GPS receiver. The loca2on provisioning is done into the LRR via the LRC. 5.2.2 Device Manager: The ThingPark Wireless Device Manager is a standard ThingPark applica2on which enables ThingPark Wireless subscribers to provision and manage their devices. It is easy to use and provides a complete end-to-end device management solu2on. Main features: geographical system informa2on where subscriber’s devices are located, detailed sta2s2cs and reports on device ac2vity, the ability to add new devices, management of Connec2vity Plan subscrip2ons and management of up to applica2on server rou2ng proﬁle.
Page 13: Recovery Information
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 7. RECOVERY INFORMATION In case there is an issue with your device or gateway, the following instruc2ons will help you to re-provision devices and gateways. 7.1 DEVICE The following snapshot helps you to provision in case it is deleted from the Device Manager: The AppEUI and AppKey are available on your Delivery no2ce form 7.2 GATEWAY The following screenshot helps you provision the gateway in case it is deleted from the Network Manager. The LRR ID can be found on the delivery note under the ID tab.
Page 14: Faq And Support
Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 8. FAQ AND SUPPORT Please refer to the following link for any further informa2on: Frequently asked questions: Please ﬁnd our FAQ page here: hkps://iot.thingpark.com/clickandgo/content/category/7-faq Should you s2ll have ques2ons aaer consul2ng this page, please send an email to customer- support@thingpark.com Make sure to ﬁll in the required informa2on: Name Surname Organiza2on Account name Login Your ques2ons You can ﬁnd the account name and login on the welcome mail you have received.
Page 15 Click & Go Extreme Cold Chain EU868 Quick Starter Guide – V1.0 © 2017 ACTILITY SA. All rights reserved. Por2ons of this documenta2on and of the soaware herein described are used by permission of their copyright owners. Ac2lity, ThingPark, are registered trademarks of Ac2lity SA or its subsidiaries and may also be registered in other countries. Other denoted product names of Ac2lity SA or other companies may be trademarks or registered trademarks of Ac2lity SA or its subsidiaries, or their respec2ve owners. Headquarters Ac2lity Lannion, Ac2lity S.A 4 rue Ampère BP 30225 22300 Lannion France www.ac2lity.com...
