Hughes HP-67005 Assembly Instructions Manual

Box blind bow stand

Hughes Products Company, Inc. assumes no liability for injury or damage to persons

or property resulting from the use of the Hughes Box Blind. The Hughes Box Blind

must be assembled, installed, anchored, and used with care, caution, and common

sense. Anchoring the Hughes Box Blind is the owner's responsibility.

Note: It will take two (2) people to assemble this box blind.

You must read all instructions before starting assembly!

(When referring to wall letters(A,B,C,&D), all walls are identical except when

referring to Wall D, which is the panel with your door cut out.)

TOOLS REQUIRED FOR ASSEMBLY:

Cordless drill

Phillips head drill bit

(1) Roof

(1) Package with screws, nuts, & bolts (extra

included in case of losing them)

(3) Walls with windows cut out bow walls

(1) Wall with window and door cut out

HUGHES BOX BLIND

BOW STAND

ASSEMBLY INSTRUCTIONS

FOR HP-67005

Measuring tape

Adjustable wrench or pliers

REQUIRED ITEMS NEEDED See pg.4/5

(1) 2 x 4 x 49" for wall support #1

(2) 2 x 4 x 45 1/2" for wall support #2

(1) 2 x 4 x 42" for wall support #3

(1) 2 x 4 x 49" door frame (top)

(2) 2 x 4 x 31- 3/4" door frame #5 & #6

(2) 2 x 4 x 58" for vertical support #7

Table of Contents

Do you have a question about the HP-67005 and is the answer not in the manual?

Page 1 Hughes Products Company, Inc. assumes no liability for injury or damage to persons or property resulting from the use of the Hughes Box Blind. The Hughes Box Blind must be assembled, installed, anchored, and used with care, caution, and common sense.
Page 2 **Platform for flooring is not included. We recommend using a 4 x 4 ft, 1/2" thick, piece of plywood as flooring. INSTRUCTIONS: 1) With wall panels A & B vertical, one person stands on the inside with nuts & the other on the outside with the screws (8-32 x 3/4) (See Fig.1).
Page 3 See window kit diagram for more info. If you would have any problems with this product, please contact HUGHES PRODUCTS COMPANY, INC. at 336-769-3788. Please do not contact the merchant where you purchased the blind.
Page 4 INSTRUCTIONS: FOR WINDOW ABOVE DOOR 1) Peel plastic film off one side of the window. 2) Peel off adhesive tape off the window handle and place on the bottom of the window in the center. Make sure the bottom lip of the handle is against the bottom edge of the window and press firmly.
Page 5 Velcro pad on the blind wall. Press the pad firmly against the wall of the blind. This will hold your window in the open position. HUGHES PRODUCTS COMPANY, INC. PO BOX 606 Wallburg, NC 27373 336-769-3788 Fax: 336-769-3792 Email us: hughesproductsco@yahoo.com...
