TEFEN
U
U
TEFEN Manufacture & Marketing Plastic Products 1990 LTD
Kibbutz Nahsholim D.N. Hof Carmel 30815
Phone 972-4-6395550 * Fax 972-4-6390813
Model 2502
s
e
r
s
M
s
e
r
s
M
U
s
e
r
s
M
Israel
http//: www.tefenplastic.com
tefen@nahsholim.org.il
E-mail:
a
n
u
a
l
a
n
u
a
l
a
n
u
a
l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MixRite 2502 and is the answer not in the manual?

Questions and answers

Related Manuals for tefen MixRite 2502

Summary of Contents for tefen MixRite 2502

  • Page 1 TEFEN Model 2502 TEFEN Manufacture & Marketing Plastic Products 1990 LTD Kibbutz Nahsholim D.N. Hof Carmel 30815 Israel Phone 972-4-6395550 * Fax 972-4-6390813 http//: www.tefenplastic.com tefen@nahsholim.org.il E-mail:...
  • Page 2 Introduction The MixRite pump injects functional additives into liquid medium systems using a uniform repeating method. Technical Data Flow Rate From 10 to 2500 L/H (From 2.6 to 660 Gal/H) Temperature From 4 C to 50 Water Pressure (intake) From 0.2 to 6 Bar (From 2.9 to 85 PSI) Range of Rate of Additive between 0.2% and 2%...
  • Page 3 Installation of the MixRite Installing the MixRite On a Direct Line (in line) Install valves to the water line on each side of the pump. Install a 50-75 mesh (250-300 micron) filter between the valve and the pump intake. Install recorder connectors to each of the pipes that connect to the pump.
  • Page 4 Installing the MixRite On a Bypass line (off line) Where water is supplied at a higher flow rate, than the working flow rate of MixRite must be installed on bypass line. The bypass provides the possibility to close the operation of the pump while water continues to flow through the line.
  • Page 5 Mounting the MixRite Prepare the MixRite site. • The MixRite intake and outlet must reach the intake and outlet pipes. • The MixRite must be positioned 1-1.5 meters above the liquid additives container. Screw the MixRite bracket onto a wall or any stable vertical base. 3.
  • Page 6 Adjusting the MixRite Every stroke of the MixRite moves a predetermined volume of water with a predetermined volume of liquid additive. To adjust the volume of the liquid additive: Preset the amount of additives according to the Percentage to Water Scale that is found on the proportioner.
  • Page 7 Troubleshooting Problem Check Solution MixRite does not Check that the intake and outlet Open the valve operate valves are open Check that Clean the filter clogged Check that water is flowing Open main and in the line or outlet valve Check that springs are not broken Change the Open pump lid &...
  • Page 8 Accessories...
