Description Of Parts - SoundLogic XT TOUCH-SP Instruction Manual

Description of Parts:

Item
1 LED indicator
2 Power / LED light
button
3 PREV / Volume
decrease (-)
4 / Phone button
5 NEXT / Volume
increase (+)
6 Mode button
7 Built-in Mic
8 LED charge indicator
9 DC charging port
10 USB slot
11 Aux-in jack
12 Micro SD (TF) slot
Function
Blue light blinks on Bluetooth pairing mode, and
stays on when Bluetooth paired successfully.
To turn ON/OFF the speaker/To adjust warm
white LED light brightness, or change different
color light mode.
Short press will skip backward to the previous
track, and long press will decrease the volume.
Play / pause button - Short press will pause or
restart the music.
Phone button - Answer / reject / end call / redial
last number. For Hands-Free Conversation
Short press will skip forward to the next track, and
long press will increase the volume level.
Switching mode of operation
For Hands-Free Conversation
Red light stays on during charging, and turns off
when speaker is fully charged.
DC Charging Port – To charge the speaker
USB input (Flash Drive)
To play music through auxiliary cable.
Micro SD (TF) card input
Operation
3
