SiteLight
Landscape Series
Portable Outdoor Floodlight
Installation Instructions
For Outdoor use ONLY!

IMPORTANT SAFEGUARDS:

Please read and understand all instructions
before beginning assembly or installation.
Check your local electrical codes to make sure
that your materials and method of installation
comply with all codes.
This is a portable fixture not intended for
permanent installation.
Use a 150-watt Par 38 floodlight bulb.
WARNING
Keep away from combustible materials.
CAUTION
Risk of shock − For wet location mounting,
aim at least 45° downwards.
45°
Risk of fire − Space housing and bulb 2"
minimum from surrounding structures.

Tools Required:

If you have any questions, call us toll free
Monday-Friday 8:00 AM to 4:30 PM
(Central Standard Time) at 1-888-862-3289.
© 2008 Thomas & Betts Corp.
Memphis, Tennessee 38125
Made in Mexico
www.tnb.com
K780 and K780BR

PARTS IDENTIFICATION

A
Splice Box Assembly (1)
B
L-800 Sub Assembly (1)
C
Gasket (1)
D
Ground Screw (1)
E
Cover Gasket (1)
F
Cover / Mounting Bracket (1)
G
Cover Screw (3/8" long) (2)
H
Bracket Screw (1" long) (2)
J
Plug (1)
K
Stake (1)
L
Wire Connectors (2)
M
Sealant (1)
B
D F H
C
A
L
G
E
J
M
K
TA03956 A
