How to use tHe sHockwatcH
ShockWatch Label Mounting Instructions
The mounting of a ShockWatch Label is important to ensure that the
indicator properly detects mishandling and impact.
1. Always place labels on the right edge of the shipment.
2. Always place labels on the longest side of your shipment.
3. The heavier the shipment, the lower you should mount the label.
ShockWatch Green Label L-30
100G's at 50ms (millisecond)
ShockWatch Orange Label L-35
75G's at 50ms
Placement is in upper right corner of the package.
ShockWatch Red Label L-47
50G's at 50ms (millisecond)
A. For packages 50 – 100 lbs. (22.68 – 45.36kg),
placement is in upper right corner of the
package.
B. For packages 100 – 500 lbs. (45.36 – 226.8kg),
placement is along the right edge, at least 24
inches (60.96 cm) from the bottom.
Intelligent monitoring and control solutions:
In Buildings | In Transit | Outdoor/Remote
label
Recommended Placement of ShockWatch Labels
