Mounting Steps
1:
Release the front cover by inserting a screwdriver into
bottom channel and twisting.
1
4:
After connecting the receiver as per wiring diagram (see diagram)*, mount the thermostat on to the
backing plate and push down wire retaining clip, remount the frame.
*All wiring must be completed by a qualified professional in line with current regulations
E8.413RF/E8.423RF Wireless Receiver (Single Zone)
✆ 0800 5420 816
2:
To release backing plate, slide wire retaining clip upwards.
www.wundatrade.co.uk
3:
Mount the backing plate in the wall socket using
a screwdriver and screws supplied.
E06
Wiring Diagram
Potential free
output
Main control
circuit
Revision Date: 30/04/2018
