- Page 1 SMART AIR PURIFIER DELUXE Manual Guide Legate Smart Appliances...
-
Page 2: Let's Get Started
Let’s Get Started. Install the app Download the Legate Smart Home from Google Play or the App Store on a compatible phone or tablet. Register and login Register on the app by using your contact number or Email address. Connect to wifi Make sure that your mobile phone and smart device are connected to 2.4 GHz... - Page 3 Legate Smart Air Purifier Deluxe to Legate Smart Home App...
- Page 4 Turn On the Smart Air Purifier, then into the power socket. press & hold the Ionizer Button for 5 seconds until the Wifi Indicator Light blink rapidly. Legate Smart Air Purifier Deluxe - Connecting the Smart Device to Legate Smart Home app...
- Page 5 Add Smart Device Open Legate Smart Home app, Under “Small Home Appliances” tab Click “+” or Add Device. Click “Air Purifier”. Legate Smart Air Purifier Deluxe - Connecting the Smart Device to Legate Smart Home app...
-
Page 6: Network Configuration
Network Configuration Click “Confirm indicator Enter your Wifi Password. Then rapidly blink” button. click “Confirm” button. (note: Only 2.4 GHz Wifi network are supported) Legate Smart Air Purifier Deluxe - Connecting the Smart Device to Legate Smart Home app... - Page 7 Wait for the Smart Device Click “Done” button when the Smart connects to the app. Device is successfully added. (note: You can change the device’s name) Legate Smart Air Purifier Deluxe - Connecting the Smart Device to Legate Smart Home app...
- Page 8 Legate Smart Air Purifier Deluxe Features...
- Page 9 Main Function Adjust the Wind Speed of Enable or Disable the different Set Schedule to automatic the Smart Air Purifier functions of the Smart turn ON/OFF the Smart Air Purifier. Air Purifier. Legate Smart Air Purifier Deluxe - Features...
-
Page 10: Push Notification
Push Notification Enable to turn off the notification. Click “Me” button on Legate Click “Push Notification” Can turn on or turn off the Smart Home app. Then click tab. “Enable notification” “Settings”. Legate Smart Air Purifier Deluxe - Features... - Page 11 The device will restore to default settings. Click “ ” button on upper Click “Remove Device” Click “Confirm” button to right corner of Smart Camera tab. completely remove the device main page. from the Legate Smart Home app. Legate Smart Air Purifier Deluxe - Features...
- Page 12 Legate Smart Air Purifier Deluxe Product Information...
-
Page 13: Product Features
The precision of the HEPA Filter is 0.01 Micron, and it is able to eliminate particles which are larger than 0.01 Micron with the Filtration Rate Of 99% or more. Dust, Bacteria, Fungi, Viruses, Allergens and other small and tiny particles are not able to get through the HEPA Filter. Legate Smart Air Purifier Deluxe - Product Information... -
Page 14: Packing Details
Floating Dust, Bacteria, Viruses and Smoke. The particles become denser and sink to the ground. The smaller the particle size, the higher the Capture Rate. Packing Details Machine Remote Control 3pcs Filter Legate Smart Air Purifier Deluxe - Product Information... -
Page 15: Product Performance
Product size 370 x 195 x 650mm Packing Size 433 x 256 x 720mm Pre-filter, Cold-catalyst, Formaldehyde removal filter (Honeycomb activated Purification carbon filter Optional), Antibacterial filter, UV Sterilization, HEPA filter, Anion release. Legate Smart Air Purifier Deluxe - Product Information... -
Page 16: Product Overview
Product Overview Control Panel Top View Front Panel Control Panel Handle Air Inlet Air Inlet Air Inlet Front View Side View Rear View Legate Smart Air Purifier Deluxe - Product Information... -
Page 17: Install Filter
Note: Please ensure the tab side is facing you. • Take out the filters • Install filter 1(Pre-filter) Note:Please ensure the handle side is facing you. • Removal all packaging material • Install front plate. Legate Smart Air Purifier Deluxe - Product Information... -
Page 18: Control Overview
Ionizer will on/off when press this button. The icon will light up and down accordingly. Motor will turn on and stay low speed mode if you press this button at standby mode. IONIZER Legate Smart Air Purifier Deluxe - Product Information... - Page 19 It will disappear after 3 seconds. Accumulated working time of the filter Power Off When machine running, it will turn into standby mode when press this button. POWER Legate Smart Air Purifier Deluxe - Product Information...
-
Page 20: Function Descriptions
Childlock mode, as long as you press the Childlock button, the control panel and buttons on the remote control can not work.(Long press 3 seconds locked to lift,or press the unlock button on the remote control) Legate Smart Air Purifier Deluxe - Product Information... - Page 21 The battery is designed for the latest 10 days standby, it runs out of battery for more than 10days,the clock function automatically reset. We need to set the clock again.(Refer to the back of the clock setting process.) Legate Smart Air Purifier Deluxe - Product Information...
-
Page 22: Installation Notice
• Special Notice: Do not place magnets and metal object. air outlet Do not block the air inlet and outlet. • For example, do not place anything on the outlet or front air inlet. air intlet Legate Smart Air Purifier Deluxe - Product Information... -
Page 23: Safety Precautions
Do not use this product in a humid or high-temperature environment (e.g.bathroom, toilet or kitchen.) toilet or kitchen.) Do not allow children to have access to the remote control. Do not allow children to have access to the remote control. Legate Smart Air Purifier Deluxe - Product Information... - Page 24 • Chemical residues may accumulate in the machine, then released from the outlet and harm to health. • After using insecticide, should thoroughly ventilate the room before using air purifier. Mandatory Items When the following occurs, please immediately turn off the power of the machine. (May cause electric shock, sparks, or smoke) •...
- Page 25 • The power cord or plug is abnormally hot. • I noticed an abnormal sound or vibration •There are any other abnormalities or malfunctions Non-professionals are prohibited from disassembling the machine to avoid the risk of electric shock Legate Smart Air Purifier Deluxe - Product Information...
-
Page 26: Cleaning And Maintenance
• Do not use water to clean the filter. Negative Ion Generator Oils • When you hear the machine with a creak sound, use the brush pen as cleaning tool, regularly clean the dust around the negative ion. Negative ion Legate Smart Air Purifier Deluxe - Product Information... - Page 27 • According to the use of places and methods (e.g. The family with many of smokers or the place with serious pollution), the filter life will be shortened. Please replace the filter in time. Legate Smart Air Purifier Deluxe - Product Information...
-
Page 28: Replacing The Filters
The machine has filter change reminding function. It’s set at 1500 hours. Please replace No.2 and No. 3 filter when “change” icon light up. Also please press the child lock button for 5 seconds to reset this function. Legate Smart Air Purifier Deluxe - Product Information... -
Page 29: Trobleshooting
--Please remove filter bag in use of the first time. air purifier quality not improved 2.Installation order filter is wrong? obviously. --Installation sequence . Please turn off the power immediately and find Display is showed “F1” or “F2” maintenance department. Legate Smart Air Purifier Deluxe - Product Information... - Page 30 Your one stop shop for all your Smart Home needs www.legate.com.sg...
