INSTALLATION AND MAINTENANCE MANUAL Index EEC DECLARATION OF CONFORMITY .............. 3 SAFETY ADVICE................... 4 GENERAL INFORMATION ..............7 1.1. DESCRIPTION OF REFRIGERATED DISPLAY CABINET ......8 1.2. GENERAL CHARACTERISTICS ............8 1.3. TECHNICAL INFORMATION AND ACCESS TO EPREL ......9 ... - Page 3 INSTALLATION AND MAINTENANCE MANUAL 4.2. INTERNAL CLEANING PROCEDURE ..........26 4.3. CONDENSER CLEANING PROCEDURE ..........26 4.4. FIXED GLASS CLEANING ............... 28 4.5. DOORS MAINTENANCE ..............31 SPARE PARTS REQUEST ..............32 FAULTS AND REPAIRS ..............33 ...
-
Page 5: Safety Advice
INSTALLATION AND MAINTENANCE MANUAL SAFETY ADVICE This cabinet contains flammable refrigerant R290. The refrigerated display cabinet must not be installed in places where explosive gases are present. Do not expose the equipment to atmospheric agents. Packaging materials (plastic bags, nails, screws, polystyrene, etc.) should not be left within reach of children as they pose potential sources of danger. - Page 6 INSTALLATION AND MAINTENANCE MANUAL Do not expose the equipment to atmospheric agents. Do not store explosive substances such as aerosol cans with a flammable propellant in the refrigerated cabinet. Keeping pharmaceuticals, glass bottles or flasks in the cabinet is strictly forbidden. Only qualified personnel can remove panels or guards, and specially the electric board cover, when this requires the use of tools.
- Page 7 INSTALLATION AND MAINTENANCE MANUAL The components of the refrigerating circuit must not be cut or separated. It is completely forbidden to perforate the cabinet. If this occur, it could create irreparable damages. If you wish to stick adhesive signs onto the cabinet, only use thin foil. Do not lay thick insulating layers on the external walls of the equipment as this could compromise cabinet performance.
-
Page 8: General Information
INSTALLATION AND MAINTENANCE MANUAL 1. GENERAL INFORMATION Welcome to the new series of plug-in refrigerated display cabinets from Frost-trol for the sale of perishable food products. We are delighted by your decision to choose This assembly and maintenance manual has been especially designed with a view to... -
Page 9: Description Of Refrigerated Display Cabinet
Fros-trol Plug-in series. LOMOND are static freezer cabinets that have been designed specifically for the sale of frozen foods and ice creams. The cabinet has a wide range of optional accessories. If you need details about its assemblage, please contact with Frost-trol, S.A. 1.2. GENERAL CHARACTERISTICS... -
Page 10: Technical Information And Access To Eprel
1.4. SHOP CONDITIONS Frost-trol refrigerated display cabinets are designed to operate in air-conditioned areas that maintain an air temperature of 25º C and a maximum relative humidity of 60 % (climate class 3, in accordance with ISO EN 23953-2). The performance of... -
Page 11: Fixation Of The Recommended Temperature In Each Compartiment
Frost-Trol Commercial Department or our official representative for your country. This refrigerated display cabinet has been thoroughly inspected to ensure the highest level of quality. Any order for components should be made to Frost-Trol or our official representative for your country within 48 hours of receipt of the cabinet. -
Page 12: Technical Assistance
Technical Department. If you need to get in contact with Frost-Trol with regard to a specific element, please make sure that you are able to quote the model and serial number. This information can be found on the nameplate, which is located inside the refrigerated display cabinet. -
Page 13: Intallation Of Refrigerated Display Cabinet
INSTALLATION AND MAINTENANCE MANUAL 2. INTALLATION OF REFRIGERATED DISPLAY CABINET Handling operations and installation of the cabinet are reserved for skilled person. 2.1. CABINET LOCATION Consult the Construction Manager or the person responsible for the installation of unit. Ask them to inform you of its installation location or if there are any changes to where it is to be installed. -
Page 14: Upacking
INSTALLATION AND MAINTENANCE MANUAL 2.2. UPACKING Unpacking is reserved for skilled personnel. The refrigerated cabinet is protected by plastic wrapping. Remove this and take out the accessories which can be found inside the cabinet: Using a fork-lift truck or pallet-lift, lift the cabinet, remove the wooden or plastic supports and replace them with the plastics bases that can be found inside the cabinet with the other accessories. -
Page 15: Assembly
INSTALLATION AND MAINTENANCE MANUAL 2.4. ASSEMBLY When assembling lines that consist of more than one unit, the units should be assembled in the correct order, i.e. their positions correspond with the numbers indicated on the side of each unit (e.g. 4 in position 4, 3 in position 3.). When the units' final positions have been determined, you may proceed to fit them together, either manually or mechanically be careful to ensure that no pressure is exerted on fragile components, such as glass, insulation glass or other weak... -
Page 16: Rear Backstoppers Mounting
INSTALLATION AND MAINTENANCE MANUAL 2.4.1. REAR BACKSTOPPERS MOUNTING: * This assembly applies to all Lomond models except when they have a back cover. SCREW ON THE SCREW ON THE TOP OF THE BOTTOM OF THE HOUSING HOUSING TRANSLATION OF THE LOMOND SOLID LINES For additional copies visit: ... -
Page 17: Side Kit Mounting
INSTALLATION AND MAINTENANCE MANUAL 2.4.2. SIDE KIT MOUNTING 1- Screw the “tapa-juntas” pieces and “tapa-juntas faldón” between them at the fixing points. 2- Screw the assembly to one of the rear of the cabinets to be assembled (see sections 2.4.3 and 2.4.4). OPTION 1 BACK TO BAK KIT MOUNTING: OPTION 2 WALL AHEAD KIT MOUNTING: TAPA-JUNTAS... -
Page 18: Wall Ahead Kit Mounting
INSTALLATION AND MAINTENANCE MANUAL 2.4.3. WALL AHEAD KIT MOUNTING 1- Fit the rear backstoppers as indicated in section 2.4.1. 2- Assemble the side kit as indicated in section 2.4.2 option 2 3- Screw the counter-wall side kit to the exterior of the cabinet using TAE 4.2x13 Galvanized screws. Screw only in the enabled points. -
Page 19: Back To Bak Kit Mounting
INSTALLATION AND MAINTENANCE MANUAL 2.4.4. BACK TO BAK KIT MOUNTING 1- Fit the rear backstoppers as indicated in section 2.4.1. 2- Screw on the ends of the set, 1 back to back side kit on each cabinet (see section 2.4.2 option 1, position 1). Mount on opposite sides. Use TAE 4.2x13 Galvanized screws. -
Page 20: Head Module Assembly Kit
INSTALLATION AND MAINTENANCE MANUAL 2.4.5. HEAD MODULE ASSEMBLY KIT 1- Mount back to back kit as indicated insection 2.4.4. xxxxx 2- Insert and screw the “tapa-juntas faldón” left and right on the head module. Use TAE 4.2x13 Galvanized screws. Screw only at the enabled point. 3- Join the head module cabinet to the assembled cabinet line. -
Page 21: Electrical Connection
INSTALLATION AND MAINTENANCE MANUAL 2.5. ELECTRICAL CONNECTION The assembly, installation and connection of these cabinets must be carried out by a certified technician. Before obtaining access to terminals, all supply circuits must be disconnected. Consult the circuit diagrams that are supplied with each cabinet when carrying out the electrical connections and observe all of your country’s safety regulations in full. -
Page 22: Operation
INSTALLATION AND MAINTENANCE MANUAL 3. OPERATION 3.1. INITIAL START-UP Before starting up the unit, allow at least one hour to pass in order to let the oil levels to stabilize, as they would have been displaced during transportation. Connect the cabinet to the mains and the display will light up showing two horizontal strips. -
Page 23: How To Access And Set Parameters
INSTALLATION AND MAINTENANCE MANUAL 3.3. HOW TO ACCESS AND SET PARAMETERS type “F” (FREQUENT, not protected by password) type “C” (CONFIGURATION, password protected) Step Action Effect Meaning Access type “F” Press After 3 seconds the display will show the 1st parameters is seconds parameter, “0”... -
Page 24: Alarms With Manual Reset
INSTALLATION AND MAINTENANCE MANUAL Category Parameters Message Icon Probe parameters ‘Pro’ Control parameters ‘Ctl’ Compressor parameters ‘CMP’ Defrost parameters ‘dEF’ Alarm parameters ‘ALM’ Fan parameters ‘Fan’ Configuration parameters H configuration ‘CnF’ HACCP parameters H HACCP ‘HcP’ RTC parameters ‘rtc’ Tabla 8. Icônes. For both types of access (type “F” and type “C”) there is a timeout (no button on the keypad pressed for 1 min), the procedure is ended without saving the parameter. - Page 25 INSTALLATION AND MAINTENANCE MANUAL Load the products into the cabinet in such a way that you can ensure ‐ good stock rotation; Empty spaces should be left between products to ensure perfect air ‐ circulation around them. Gloves should be worn when loading products into the cabinet. The cabinet doors should be closed as long as possible.
-
Page 26: Maintenance And Cleaning
INSTALLATION AND MAINTENANCE MANUAL 4. MAINTENANCE AND CLEANING Unplug the cabinet before performing any form on internal servicing of the unit. Any maintenance operation not described in these instructions must be done by authorized personnel. Perishable products are sensitive to the bacteria proliferation. Therefore, cabinet cleaning has to be made following next generic rules. -
Page 27: Internal Cleaning Procedure
INSTALLATION AND MAINTENANCE MANUAL For glass surfaces cleaning, use specific products for it. Water use, will carry on calcareous deposits. For cleaning the fixed glass, pleas follow the procedure described in the next section. 4.2. INTERNAL CLEANING PROCEDURE To ensure an adequate level of hygiene of your cabinet you must clean and disinfect the inner parts of the cabinet almost every 30 days. - Page 28 INSTALLATION AND MAINTENANCE MANUAL Use a soft nonmetal brush or a vacuum cleaner. ‐ Mount and screw the front grille. ‐ Finally, plug de cabinet. ‐ The condenser’s coil must be cleaned 12 times a year. Otherwise, the efficiency of the appliance might drop significantly. TRANSLATION OF THE LOMOND SOLID LINES...
-
Page 29: Fixed Glass Cleaning
INSTALLATION AND MAINTENANCE MANUAL 4.4. FIXED GLASS CLEANING For glass surfaces cleaning, use specific products for it. Water use, will carry on calcareous deposits. For cleaning the fixed glass, pleas follow the procedure described in the next section. CENTRAL BACKSTOPPER FIXED GLASS SIDE BACKSTOPPER CENTRAL POST TRANSLATION OF THE LOMOND... - Page 30 INSTALLATION AND MAINTENANCE MANUAL 1- With a 2.5 Allen wrench unscrew the central backstopper located in the center of the island, on the central post. CENTRAL BACKSTOPPER 2- Remove the central backstopper. 3- Then slide softly the glass in question and pull it until it disengages from the lateral guide.
- Page 31 INSTALLATION AND MAINTENANCE MANUAL 4- Proceed to cleaning the glass. To do this, always place the glass on flat surfaces on which it rests its entire surface in order to avoid breakage. 5- Once the surface is cleaned, verify that all the rubber seals remain correctly mounted and replace the glass in its initial position.
-
Page 32: Doors Maintenance
INSTALLATION AND MAINTENANCE MANUAL 6- Place the central backstoper at the fixing point and screw to the central post. Pay special attention to the mounting position of the central backstoper. The groove of the central backstopper must fit with the fixed glass. 7- Finally, screw the central bakcstopper until it is properly fixed. 4.5. -
Page 33: Spare Parts Request
*The series number is indicated inside the refrigerated cabinet, on the characteristics plate. ** Taking the customer’s standing position as a reference. *** You may request to Frost-trol the spare parts cross-section. Tabla 10. Name plate According to point 2 in the Annex II from the Regulation 2019/2024 (Ecodesign),... -
Page 34: Faults And Repairs
INSTALLATION AND MAINTENANCE MANUAL 6. FAULTS AND REPAIRS 6.1. MALFUNCTIONS In the event of malfunction, the operator should take all necessary measures to prevent the products from deteriorating. 6.1.1. THE UNIT DOESN’T START UP OR IT STOPS: Check that the electricity supply is sufficient. ‐... - Page 35 INSTALLATION AND MAINTENANCE MANUAL Cabinet model, serial number and manufacturing date (in the case name plate): Store conditions (RH in %, room temperature): If there are any air draughts affecting the cabinet (doors, air conditioners, other plug in cabinets near, etc.) (a handmade drawing or photos could be appreciated); Thermostat setting: Defrost interval: Defrost endurance time:...
-
Page 36: Final Shutdown
INSTALLATION AND MAINTENANCE MANUAL 6.2. FINAL SHUTDOWN We, Frost-trol SA, declare this product is covered by Directive 2002/96/CE (Waste Electrical and Electronic Equipment) designed to halt the increase of this type of waste and promote recycling as well as decreasing disposal. The symbol of the crossed-out waste bin that appears on the Nameplate declares: that the product was put in circulation after 13th ‐... -
Page 37: Declartion Of Rohs Conformity
INSTALLATION AND MAINTENANCE MANUAL 6.4. DECLARTION OF ROHS CONFORMITY We, Frost-trol, S.A. declare under our sole responsibility that the refrigerated cabinet complies with the provisions of Directive 2002/96/EEC (RoHS). In all the homogeneous materials used for its production, any content of lead, mercury, hexavalent chrome, polybrominated biphenyl (PBB), and polybrominated diphenil ether (PBDE) does not exceed, in weight 0.1%;... - Page 38 ESPAÑA PLANTA CABANES: CV 159 Km 2 - 12180 Cabanes (Castellón), Spain -Tel. (+34) 964 342 740 - Fax. (+34) 964 215 148 - info@frost-trol.com MÉXICO: Av. Pirules, 134 B esquina con Av.Tejocotes, Fraccionamiento San Martin Obispo Cuautitlán Izcallí CP 54769, Estado de México - Tlf. (+52) 55 58193189 - info.mx@frost-trol.com...
