Quick Installation Guide

This Quick Installation Guide only provides you with some basic instructions. For more
detailed information, please refer to the User Manual on the supplied CD.
Model # RT211W
Connecting the Access Poing (AP)
1
Prior to connecting the hardware, make sure to power off
your Ethernet device, Cable/ADSL modem and AP. Then
follow the steps below to connect the related devices.
Step 1
Connecting the power adapter.
Connect the single DC output connector of the power adapter
to the power jack on the back of the AP. Then connect the
supplied power cord to the power adapter and the other end to
an AC outlet.
Step 2
Connecting to Ethernet network.
Attach one end of the Ethernet cable with RJ-45 connectors to
your hub, switch or a PCs Ethernet port, and the other end to
the LAN port of your AP.
Ver. 5A
Package Content:
802.11g access point
Power Adapter
Category 5 UTP cable
Utility CD
Quick Installation Guide
Setting Up Ethernet/WLAN Client
2
You can choose to access the APs Web interface via Ethernet or
wireless network. Whatever your choice, you must properly
configure the network settings of your PC to be in the same
subnet with the AP. As the AP is shipped with these defaults:
IP address: 192.168.1.1
Subnet mask: 255.255.255.0
DHCP server: Disabled
Therefore, you should configure your PC's TCP/IP settings to use
a static IP as below:
IP address: 192.168.1.x (x is between 2 and 254)
Subnet mask: 255.255.255.0
Gateway: 192.168.1.1
Note: Before you change the TCP/IP configuration, you should write
down your original configuration setting in case you need to restore it
later.
Step 1
Click the Start button. Select Settings and/or click the Control
Panel icon.
For Windows 98 and ME, double-click the Network icon.
For Windows 2000, double-click the Network and Dial-up Con-
nections icon. Double-click the Local Area Connection x.
For Windows XP, click the Network and Internet Connections
icon. Click the Network Connections. Double click the Local
Area Connection x under LAN or High-Speed Internet.
