Luraco L1004B-KP-V3 User Manual

10-Button Keypad with Temperature Display for PSC/BSC
Display
1
2 Temperature
Speed level
3
Time remaining
4
5 Jet pump button
Speed + button
6
Speed – button
7
8 Pulse mode
button
USER'S MANUAL
(Model: L1004B-KP-V3)

Understanding the Unit

Screen OFF: Unit is in 'idle' mode
Screen ON: Unit is displaying speed, time remaining or error
information.
When on, the screen displays the water temperature in
degree F
When on, the screen displays speed level from 1 to 10
of the corresponding pump.
When on, the screen displays the cycle time remaining in
minutes.
st
1 press: Jet pump ON, Light ON, LED ON
nd
2 press: Jet pump OFF, LED OFF
Speed goes up, screen displays speed. Max. speed level is
10.
Speed goes down, screen displays speed. Min. speed level
is 1.
st
1 press: Pulse mode ON, LED ON
nd
2 press: Pulse mode OFF, LED OFF
