INSTRUCTION MANUAL
Orion Dual Finder Scope Mounting Bracket
Francais
Pour obtenir le manuel d'utilisation complet,
veuillez vous rendre sur le site Web OrionTele-
scopes.eu/fr et saisir la référence du produit dans
la barre de recherche.
Cliquez ensuite sur le lien du manuel
d'utilisation du produit sur la page de description
du produit.
Deutsche
Wenn Sie das vollständige Handbuch
einsehen möchten, wechseln Sie zu OrionTele-
scopes.de, und geben Sie in der Suchleiste die
Artikelnummer der Orion-Kamera ein.
Klicken Sie anschließend auf der Seite mit
den Produktdetails auf den Link des entsprech-
enden Produkthandbuches.
Español
Para ver el manual completo, visite
OrionTelescopes.eu y escriba el número de
artículo del producto en la barra de búsqueda.
A continuación, haga clic en el enlace al
manual del producto de la página de detalle del
producto.
#10145
Congratulations on your purchase of a quality
Orion accessory. Your new Orion Dual Finder
Scope Mounting Bracket is a terrific accessory
that enables two aiming devices to be used at
the same time on one telescope.
Included Items:
• Bracket
• dovetail mounting shoe for finder scopes
(x2)
• Philips head screws (x4)
Assembly
• Attach each of the dovetail mounting
shoes to the bracket using the included
screws and a Philips head screwdriver (not
included) making sure that both the bases
are oriented in the same direction as the
base of the bracket (Figure 1).
Figure 1. Rear view of bracket showing orientation of
bracket and dovetail mounting shoes to fix to bracket
using screws.
A N E M P L O Y E E - O W N E D C O M P A N Y
Corporate Offices: 89 Hangar Way,
Watsonville CA 95076 - USA
Toll Free USA & Canada: (800) 447-1001
International: +1(831) 763-7000
Customer Support: support@telescope.com
Copyright © 2020 Orion Telescopes & Binoculars. All
Rights Reserved. No part of this product instruction or
any of its contents may be reproduced, copied, modified
or adapted, without the prior written consent of Orion
Telescopes & Binoculars.
IN 486 Rev. A 05/13

Advertisement

loading
Need help?

Need help?

Do you have a question about the 10145 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ORION TELESCOPES & BINOCULARS 10145

  • Page 1 INSTRUCTION MANUAL Orion Dual Finder Scope Mounting Bracket #10145 Congratulations on your purchase of a quality Orion accessory. Your new Orion Dual Finder Scope Mounting Bracket is a terrific accessory that enables two aiming devices to be used at the same time on one telescope.
  • Page 2 Attaching the Bracket to a Telescope Once assembled simply slide the bracket into the telescope’s dovetail mounting shoe (Figure 2) and tighten the thumbscrew on the shoe to secure the bracket. Attaching Aiming Devices to the Dual Mounting Bracket Many combinations of accessories can now be used at the same time (Figure 3).
