ARV-QC FEATURES:
- New advanced lightweight
multi-composite material.
- State-of-the-Art pivoting Key-Lock
system.
- Fast donning and doffing.
- One-size fits all.
- Structural "O" Ring for Tag/Trail Line
or handcuffs/flex-cuffs.
- Rated to 4000 lbs (18kN) MBS
Operational Use:
- Hoist/Winch Operations.
- Short Haul Operations.
- High Angle/Rapid Rescues.
Packaged Dimensions:
- 14 inch x 9 inch x 9 inch.
- Weight 6 lbs 0 oz (2.7 kg).
Max Load:
- Single person - 400 lbs.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARV-QC and is the answer not in the manual?

Questions and answers

Summary of Contents for ARS ARV-QC

  • Page 1 ARV-QC FEATURES: - New advanced lightweight multi-composite material. - State-of-the-Art pivoting Key-Lock system. - Fast donning and doffing. - One-size fits all. - Structural “O” Ring for Tag/Trail Line or handcuffs/flex-cuffs. - Rated to 4000 lbs (18kN) MBS Operational Use: - Hoist/Winch Operations.
  • Page 2 PART NUMBER: DATE OF MANUFACTURE: DATE IN SERVICE: Certificates - Airworthiness Certificate for US Army UH/HH-60 AWR980 (P/N: ARV-QC-M) - Airworthiness Certificate for US Army UH-72A AWR9 (P/N: ARV-QC-M) - Airworthiness Certificate for US Navy/US Marine Corp NA13-1-6.5 (P/N: ARV-QC-M19) Copyright ©...
  • Page 3 AIR RESCUE SYSTEMS CORPORATION AIR RESCUE VEST QUICK CONNECT PRODUCT MANUAL LIST OF EFFECTIVE PAGES Original Document Date: 05/01/2016 Current Manual Version: D (11/22/2019) PAGE # REVISION DATE PAGE # REVISION DATE 11/22/2019 05/01/2016 09/01/2019 09/01/2019 11/22/2019 05/01/2016 11/22/2019 01/20/2017 01/20/2017 01/20/2017 01/20/2017...
  • Page 4 Failure to follow these warnings increases the risk of injury and death. A five-year life span is the maximum authorized use of ARS products following the date manufacture. All ARS products have a five-year shelf life from the effective date of manufacture.

  • Page 5: Table Of Contents

    5.0 Product Care..................20 5.1 Maintenance and Inspection..........20 5.2 Advanced Inspection............20 5.3 Storage Instructions............20 5.4 Cleaning Instructions............20 5.5 Post Salt Water Exposure...........20 APPENDICES I - ARV-QC Inspection Log............21 II - ARV-QC Label Packet............22 Initials: RF Doc Number: D1092 Rev Date: 1/20/2017 Page: 3...
  • Page 6 Page: 4 Rev Date: 9/1/2019 Doc Number: D1092 Initials: RF...

  • Page 7: General Information

    1.0 GENERAL INFORMATION 1.1 INTRODUCTION - The Air Rescue Systems Air Rescue Vest Quick Connect or ARV-QC is a reinvention of the tried and true ARS Air Rescue Vest. The ARV-QC utilizes a highly engineered Key-Lock lift system quick connect device that improves safety and eliminates the need for a carabiner. Furthermore the ARV-QC incorporates all new lightweight materials that significantly reduce overall system weight.

  • Page 8: Standards And Certifications

    • A routine inspection must be performed every time the device has been stored for a period greater than 30 days. • A five-year life span is the maximum authorized use of ARS products following the date of manufacture. All ARS products have a five-year shelf life from the effective date of manufacture.

  • Page 9: User Operation

    2.1.1 ARV-QC label information Read all product documentation and store in a secure location. Create a copy of all product documentation and keep with the ARV-QC for reference. A copy of this manual may be found online at www.airrescuesystems.com. • Perform an initial inspection before using the ARV-QC.

  • Page 10: Securing The Key-Lock System

    • Once a victim’s arms are outside ARV-QC they should be instructed to place their hands on the stiff webbing above the attachment point as...
  • Page 11 Figure 5. 2.3.3 GRAB - The tail lock plate • Grab the ARV-QC tail and pull it up between the legs of the victim. • Optionally, this device can be secured and flown in the method detailed in section 2.4.1 - Quick Pick Configuration.
  • Page 12 • Manual pressure to keep the Key- Lock plates joined is no longer needed. • For instruction on how to properly attach the ARV-QC to your hoist or short haul line please refer to section 2.5. Figure 8.

  • Page 13: Optional Features

    • event speed paramount to achieving a safe and successful extraction, the ARV-QC can be used in the quick pick configuration. • Utilizing this method is at the discretion of the trained rescue specialist. It is understood that by using this configuration, the safety Key-Lock system is being bypassed.
  • Page 14 Type I helmet, ear protection, and eye protection. • ARS recommends all victims be flown or extracted with a professional, trained rescue attendant. • The ARV-QC bag is designed to accom- modate proper victim personal protec- tive equipment for ease of deployment. Figure 11. Page: 12...
  • Page 15 PAGE INTENTIONALLY BLANK Initials: RF Doc Number: D1092 Rev Date: 1/20/2017 Page: 13...

  • Page 16: Extraction And Flight

    • The rescue attendant can make in flight adjustments for the increased comfort of the victim by lifting the victims legs and pulling the ARV-QC up towards the knee. This action will help seat the victim deeper into the device providing more support.
  • Page 17 2.5.2 SHORT HAUL - Attaching ARV-QC to a HELA Rig • When attaching a packaged victim to a shorthaul HELA Rig the attachment should be executed as depicted. • Attach one paired leg of HELA Rig carabiners directly into the large eye of the Key-Lock Lift System.
  • Page 18 Figure 14. 2.5.5 HOIST - Attaching ARV-QC to the ARS 2-Up (Quick Pick Configuration) • Limiting leg twist, attach one 2-Up 3-stage auto-lock carabiner directly into the large eye of both Key-Lock plates and the large eye of the tail lock plate.

  • Page 19: Additional Products

    3.0 ADDITIONAL PRODUCTS The ARV-QC is compatible with a variety of additional products and safety equipment. It is the responsibility of the user to learn and understand the operational requirements, strength ratings, and airworthiness limitations of all equipment not listed in this product manual that is used in conjunction with the Air Rescue Vest Quick Connect.

  • Page 20: Stowing Procedures

    4.0 STOWING PROCEDURES In order to ensure the ARV-QC is flight ready and correctly configured for a safe, easy, and quick deployment it is imperative the device is stowed properly after every use. Step 4.1 • Lay the ARV-QC on a clean flat surface with the inside facing up.
  • Page 21 Key- Lock plates exposed. Figure 20. Step 4.4 • Tightly roll the ARV-QC from the bottom of the device towards the head. • When properly rolled the ARV-QC Key-Lock plates should be protruding from the top of the roll as depicted.

  • Page 22: Product Care

    5.0 PRODUCT CARE 5.1 MAINTENANCE AND INSPECTION - • Before and after each use, inspect the ARV-QC to ensure that it is in a serviceable condition. • Check for worn or damaged parts. • Ensure all hardware (D-Rings, Key-Lock Plates, etc) are present.

  • Page 23: I - Arv-Qc Inspection Log

    In-Service Date: _________________ Aircraft: ______________________________Part Number:__________ The Air Rescue Vest Quick Connect (ARV-QC) Victim Extrication Device (VED), should be inspected before and after each use. ARV- QC’s found to be damaged, excessively worn, or subjected to shock-loading forces must be removed from service immediately.

  • Page 24: Arv-Qc Label Packet

    APPENDIX II ARV-QC LABEL PACKET ..>- � � "' � � � ::::, >- <( � � � � <( "' er"" :::, z � � � � '° I;::: <( � "' '° � u. z � �...
