SPECIFICATIONS
Model no
Free Speed
Wheel size
Air Consumption
Length
Weight
Air Pressure
Air inlet
Air Hose
AIR SUPPLY
WARNING! Ensure the air supply is clean and does not exceed 90 psi while operating the Tool.
Too high an air pressure and unclean air will shorten the product life due to excessive wear and
may be dangerous causing damage and/or personal injury.
1. Ensure tool air trigger/lever is in "off" position before connecting to the air supply.
2. You will require an air pressure of 90 psi and an air flow according to specification.
3. Drain the compressor air tank daily. Water in the air line will damage the tool.
4. Clean the compressor air inlet filter weekly.
5. Line pressure should be increased to compensate for unusually long air hoses (over 8 mts).
The minimum hose diameter should be 1/4" I.D and fittings must have the same inside
dimensions.
6. Keep hose away from heat, oil and sharp edges. Check hose for wear and make certain that all
connections are secure.
PNEUMATIC ANGLE GRINDER 7K INCH
DAG – 7K
9,500 rpm
7"
12 cfm
330 mm (approx)
2.1 kgs (approx)
90 psi (6.2 bar)
1/4" bsp
10 mm
dompneumatics@yahoo.com
www.dompneumatics.com
Advertisement
Table of Contents
Summary of Contents for DOM DAG-7K
- Page 1 PNEUMATIC ANGLE GRINDER 7K INCH SPECIFICATIONS DAG – 7K Model no Free Speed 9,500 rpm 7” Wheel size Air Consumption 12 cfm Length 330 mm (approx) Weight 2.1 kgs (approx) Air Pressure 90 psi (6.2 bar) 1/4” bsp Air inlet Air Hose 10 mm AIR SUPPLY...
- Page 2 WARNING: Ensure you have read, understood and apply safety instructions before use. ASSEMBLY 1. The Dom angle grinder comes with a handle and two spanners. 2. The handle screws into the left-hand side of the head. 3. Remove the disc locking flange nut from the grinder spindle. Use the spanners supplied to hold the spindle and loosen/tighten the lock nut.
