SY0.5 Drum Synthesizer
Mode Increment
Sweep Dir.
Sweep Speed
Trigger Indicator
Decay CV
Trigger IN
Pitch CV (1v/Oct)
Specifications:
Current Draw: +12V 130 mA, -12V 20 mA
Size: 10HP, 20mm Max depth
CV Range: +/-10V. Faders act as a CV offset
Pitch Scaling: 1V/Oct
OSC Mode CV Range: 0-5V or 5V Gate
PSIpower: Either way power header
S/H
On/OFF
User Guide
Mode Decrement
LFO Shape
LFO Speed
LFO indicator
Filter CV
Output
Mode CV/Gate
Advertisement
Summary of Contents for MICHIGAN SY0.5
- Page 1 SY0.5 Drum Synthesizer User Guide Mode Increment Mode Decrement LFO Shape Sweep Dir. LFO Speed Sweep Speed LFO indicator Trigger Indicator Filter CV Decay CV On/OFF Output Trigger IN Mode CV/Gate Pitch CV (1v/Oct) Specifications: Current Draw: +12V 130 mA, -12V 20 mA Size: 10HP, 20mm Max depth CV Range: +/-10V.
- Page 2 0SC MODE LFO FADER: Controls the amount of pitch (from the Pearl Manual) movement, at the speed determined by the LFO section. Setting the fader to 0 turns off the LFO The wave frequency, variation range, and noise of modulation. the 2 osciIIIators are pre-set.
