2020/11/30 23:55
MyCloud Mini
The MyCloud Mini is designed for one portable 2.5" SATA hard drive. It provides safe and secure
network storage plus the ability to easily share your digital content with family and friends. Stream
content within your local network to any available UPnP-AV and DLNA device (e.g. PS3, iTunes,
Windows 7, etc.). Remotely access your files through any internet connected computer or through our
free iPhone, iPad and Android apps.
CPU
Memory
Internal hard drive
Front I/O
Rear I/O
Front View
Flashing blue System is starting up
Blue
System is running and ready
Red
System error (system is unable to start up)
MyAkitio Wiki - http://wiki.myakitio.com/
•
Dual-core 750MHz (SOC)
•
256MB DDR2 SDRAM
•
256MB NAND flash
•
2.5" SATA-I or SATA-II hard drive
•
HDD height 9.5mm - 14.8mm
•
Capacity 20GB - 1.5TB (supports large volumes in excess of 2TB)
•
XFS file system
•
1 x Dual color status LED
•
1 x Power receptacle
•
1 x RJ45 connector (10/100/1000) with two LEDs for link and activity
•
2 x USB 2.0 host connectors
•
1 x eSATA host connector
•
1 x Reset button
•
1 x Power button
1/3
MyCloud Mini
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Akitio MyCloud Mini
Summary of Contents for Akitio MyCloud Mini
- Page 1 MyCloud Mini MyCloud Mini The MyCloud Mini is designed for one portable 2.5“ SATA hard drive. It provides safe and secure network storage plus the ability to easily share your digital content with family and friends. Stream content within your local network to any available UPnP-AV and DLNA device (e.g. PS3, iTunes, Windows 7, etc.).
- Page 2 Last update: 2014/12/23 17:38 mycloud_mini http://wiki.myakitio.com/mycloud_mini Rear View Power button DC 5V Power receptacle USB 2.0 host port eSATA eSATA host port 10/100/10000 Gigabit Ethernet port Reset System reset button Security lock slot To reset the configurations (e.g. admin password and network settings), make sure the power is ON and the system is running.
- Page 3 2020/11/30 23:55 MyCloud Mini device and remove the power supply from the wall socket. HDD Installation Remove the screws on the bottom of the case and lift up the top of the enclosure. Install the hard drive in the HDD chassis and fasten the screws on the side to hold it in place.
