Monster Broom / Double-
Play Monster Broom
Assembly Instructions

Tools Needed for Assembly:

- 7/16" wrench (two)

Parts Shipped with Unit:

- Head
- Fluted Handle (2)
- Curved handle w/ rubber grip
- Bolt bag

Assembly instructions for handle:

1. Insert each end of the padded handle into the open end of each
ribbed handle. After making sure the arrows on the ribbed handles
face inward (toward each other), align the holes and position the
hook for each handle, as shown, and insert the longer bolts.
2. Align holes in slotted end of each ribbed handle over the holes in
the head. Insert shorter bolts.
3. Tighten all loc nuts, being careful not to over-tighten. Over-
tightening may result in crushing the handle, thereby
compromising its strength.

Assembly Instructions for Brush Replacement:

1. On one end of broom head, remove the two screws and
end cap.
2. Holding broom securely, pull out each row of bristles.
NOTE: This may require some effort, as bristles are
tight.
3. Make sure bristle channel(s) are clean.
4. Slide replacement bristle(s) into channel. Light tapping
with a hammer may be required.
5. Replace end caps and screws.
