Doughboy Media Master 1600 Owner's Manual page 7

ITEM PART #
*1 1121-1572
2 1107-1636
3 1107-1608
4 330-1023
5 387-1003
6 346-1035
7 308-1252
8 330-1260
9 340-2183
10 308-1234
11 330-1024
12 340-2174
13 340-1969
14 340-1835
15 340-2046
16 308-1241
17 340-1187
18 308-1044
19 327-1006
20 396-1018
21 1107-1486
22 330-1234
23 378-1016
24 327-1007
25 340-1188
26 340-1189
27 340-1195
28 346-1013
29 340-1224
30 308-1039
31 395-1014
32 307-1022
33 1121-1472
34 330-1235
35 343-1100
36 321-1004
37 340-2175
38 340-2200
39 307-1001
40 340-1962
41 308-1225
42 330-1245
43 365-1794
44 368-1073
*
Includes Items 38, 39, and 40.
PARTS LIST
MEDIA MASTER MODEL 1600
QTY
1 Tank
1 Underdrain Base Assembly
2 Underdrain Assembly
4 #8 x 5/8" Screw
6 Hose Clamp
2 1-1/2" x 8' Hose
1 O-ring - 7.225 I.D. x .275 c/s
2 1/4-20 x 1-1/2" Mach. Screw
1 Tank Clamp
1 O-ring - 5.850 I.D. x .250 c/s
4 #12 x 3/4" Screw
1 Upper Distributor
2 Union Hose Adaptor
2 Union Nut
1 Union Plug
2 O-ring - 50mm I.D. x 4mm c/s
1 Valve Rotor
1 O-ring - .863 I.D x .116 c/s
2 Bearing Washer
1 Valve Spring
1 Valve Cover w/Decal
6 12-24 x 1-1/4" Mach. Screw
1 Handle Pin
2 Friction Washer - Delrin
1 Valve Handle
1 Valve Handle Cap
1 Pin Retainer
1-1/2" x 2-1/2' Hose
1
1 Hose Adaptor
1 O-ring - 1.925 I.D. x .103 c/s
1 2" Pressure Gauge
Valve Gasket
1
Valve Body/Gasket Assembly
1
12-24 Hex Nut
6
1 Air Relief
1/4-20 Hex Nut
2
Valve/Tank Adaptor
1
Drain Screen
1
Drain Cap Gasket
1
Drain Cap
1
5/16" Thread Seal
1
5/16-18 x 1-1/4" Bolt
1
Owner's Guide
1
Warranty Card
1
7
DESCRIPTION
