AUTOMATIC CONVEYOR
VEGETABLE PLANTERS
S290
S290/1 - 4-
S290/2 - 5-
Printed in Węgrów by Bomet
OWNER'S MANUAL
WARRANTY CARD
SPARE PARTS CATALOGUE
Gemma
- 3-
ROW PLANTER
ROW PLANTER
ROW PLANTER
PRIOR TO STARTING WORK, PLEASE READ THIS
Spółka z ograniczoną odpowiedzialnością
07-100 Węgrów, ul. B. Joselewicza 2
Węgrów 2019, Edition 1, Eng
®
.
OPERATING INSTRUCTIONS
BOMET
Spółka Komandytowa
tel. (+48 25) 691 78 06
®
Original manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gemma S290 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bomet Gemma S290

  • Page 1 PRIOR TO STARTING WORK, PLEASE READ THIS OPERATING INSTRUCTIONS ® BOMET Spółka z ograniczoną odpowiedzialnością Spółka Komandytowa 07-100 Węgrów, ul. B. Joselewicza 2 tel. (+48 25) 691 78 06 Węgrów 2019, Edition 1, Eng ® Printed in Węgrów by Bomet Original manual...
  • Page 2 ® Copying of the manual or its parts is allowed only with the written permission of Bomet...
  • Page 3 Spółka Komandytowa 07-100 Węgrów, ul. B. Joselewicza 2 tel. (+48 25) 691 78 06 http:www.bomet.pl; e-mail: bomet@bomet.pl DECLARATION OF CONFORMITY for a machine According to the Ordinance of Minister of Economy of 21 October 2008 (Journal of Laws "Dziennik Ustaw" No.

  • Page 4: W A R R A N T Y C A R D

    W A R R A N T Y C A R D S290 Automatic vegetable planter type Serial number ..........….. Date of production..Inspector signature ..........Date of sale ..........Seller signature ............................Seller stamp Manufacturer stamp CAUTION: It is seller’s obligation to fill in the warranty card and complaint forms carefully (legibly).
  • Page 5 Complaint form No. 1 Automatic vegetable planter S290 Serial number ........Date of sale ..................seller’s signature and stamp Complaint protocol number ......Complaint form No. 2 Automatic vegetable planter S290 Serial number ........Date of sale ..................seller’s signature and stamp Complaint protocol number ......
  • Page 6 After repair I received technically efficient machine on ..........…………………………………………………….. user’s signature Notes: ........................................................................After repair I received technically efficient machine on ..........…………………………………………………….. user’s signature Notes: ........................................................................After repair I received technically efficient machine on ..........……………………………………………………..
  • Page 7 IDENTIFICATION AUTOMATIC VEGETABLE PLANTER The S290 automatic conveyor vegetable planter is a 3-row, 4-row or 5-row machine with a rating plate, fitted in the front part of the planter frame. Basic data which serves for identification of the machine: manufacturer’s name, machine symbol, serial number, year of production, is put there.

  • Page 8: Table Of Contents

    TABLE OF CONTENTS W A R R A N T Y C A R D ......................... 2 1. INTRODUCTION ..........................7 2. INTENDED USE OF THE PLANTER....................7 3. SAFETY PRECAUTIONS AND WARNINGS ................... 8 3.1. Symbols: meaning and application ................... 8 3.2.

  • Page 9: Introduction

    1. INTRODUCTION Dear customer, ® Congratulations on the choice of the product of Bomet company. The aim of this manual attached to each machine is to make a user acquainted with a construction, operation and adjustment of the automatic conveyor planters. Its aim is also warning about existing or possible threats.

  • Page 10: Safety Precautions And Warnings

    3. SAFETY PRECAUTIONS AND WARNINGS 3.1. Symbols: meaning and application In the present manual symbols are used in order to draw the reader’s attention and stress certain particularly important aspects requiring discussion. DANGER This indicates danger, with a possible serious accident risk. Not obeying recommendations marked with this sign may cause a situation of a serious risk of sustaining an injury by the operator and/or people nearby! Obey strictly these recommendations! CAUTION...

  • Page 11: Assessment Of Residual Risk

    ® Although BOMET company takes responsibility for pattern-designing and construction in order to eliminate danger, certain risk elements during automatic planter operation are unavoidable.
  • Page 12  The planter shall be stored in a dry room, on the tough and flat ground. When lowering the planter onto the ground, keep particular caution. Danger of injury!!! Aggregation  Keep particular caution when connecting the planter with a tractor and during disconnection.

  • Page 13: Standard Conformity

    Transportation  Transportation of a planter by means of transport from the manufacturer to a sales person or a client is described in the section ‘Transportation on public roads’ in detail. One shall remember safety rules during the loading and proper fixing of the planter on a car trailer. Hooks for ropes or chains are marked with pictograms.

  • Page 14: Manufacturer's Responsibility And Guarantee

    General provisions. 3.7. Manufacturer’s responsibility and guarantee ® In relation to the machine described in this manual, Bomet company does not acknowledge any civil responsibility towards: - using the machine improperly or inconsistently with the manufacturer’s recommendations,...

  • Page 15: Usage Regulations

    Table 1. Safety signs and captions Pictogram Meaning Location (Rating Rating plate At the front of the frame plate) Before operating the machine, read the At the front of the three- manual. point suspension system Caution. Before operation turn off the At the front of the three- engine and remove the key from the point suspension system...

  • Page 16: Construction And Operation Of The Machine

    4.2. Construction and operation of the machine The S290 automatic conveyor planter (Figure 1) is a machine mounted on the tractor three-point suspension system. Planters have a modular construction, they have the same elements, they only differ in the number of rows. The planter is available as a 3-row, 4-row or 5-row machine.

  • Page 17: Equipment And Fittings

    (11) which supply furrows with seeds. The planting depth is adjusted in strokes with front support wheels (12). At the back of the planter there are press wheels (13) and a leveling roller (14). The roller covers the seeds and levels the ridges. The planter is equipped with seats (15) and a platform (16) facilitating the control of filling the cups with seeds.

  • Page 18: Preparing The Planter For Operation

    4.5. Preparing the planter for operation Preparation of a new planter to operation and after storage period (e.g. after winter) consists in checking its technical condition and most of all durability of connections of working elements with the frame. In case of stating damage or worn elements it is necessary to exchange them into new or regenerated ones.

  • Page 19: Adjustment And Setting Of The Planter

    Disconnecting the planter from the tractor is performed in reverse order, it is necessary to leave the machine on the flat and even ground and secure it against moving. 4.7. Adjustment and setting of the planter The correct and good quality of the planter's work depends on the proper leveling of the planter and then depending on the crop, the appropriate setting of the planting depth, setting of the inter-row width and the planting spacing in a row.
  • Page 20 Changes in planting spacing in a row are made by changing the upper drive wheel in the drive gear. Depending on the crop, the seed sowing should be set properly in the row. By changing the gear wheel, the rotational speed of the drive shaft of the transport chain conveyor is changed.

  • Page 21: Operation With The Planter

    The change of planting spacing begins with the removal of the side shield (1) and loosening three M8x20 bolts (3) fastening the roller tensioner (2), which will allow to remove the drive chain (4) from the upper gear wheel (5). Then the replaceable gear wheel can be freely removed from the upper drive roller.

  • Page 22: Technical Operation

    CAUTION Returns shall be performed gently with the planter raised to the transport position, with no use of the tractor independent brake. It is necessary to keep extreme caution if there are people or items in the range of the planter operation. CAUTION It is not allowed to use tractor reverse gear during work, when the machine is in the working position.

  • Page 23: Replacement Of The Working Elements

    Light and warning signs and a triangular sign for low-speed vehicles should be uninstalled from the planter and placed in a dry room, to be protected from being damaged. 5.4. Replacement of the working parts In the planter there may be the need to replace wearing parts, i.e. markers or cups of the chain conveyor.

  • Page 24: Detection And Removal Of Inefficiencies

    5.6. Detection and removal of inefficiencies During operation, following failure may occur, which can affect unfavorably the planter operation quality, raise the application cost and also lead to damage both to the planter and the tractor. REMEMBER! Work with an inefficient, improperly adjusted machine may lead to serious threats to the operator and other people.

  • Page 25: Disassembly

    If the machine, when lifted to the transportation position, covers the tractor lights, it is necessary to use the complete rear marking, i.e.: two portable warning signs installed in the brackets at the back of the frame, the signs should be equipped with combination lamps and reflective red lights visible at the back as well as white side lights visible at the front, sign for low speed vehicles installed in the bracket at the back in the center, Warning signs shall be installed firmly in the brackets and the plug shall be connected...

  • Page 26: Technical Charateristics

    9. TECHNICAL CHARACTERISTICS Technical data of the mounted automatic conveyor vegetable planter of the S290 series is listed in table 5. Table. 5. Technical characteristics of the S290 planter Unit of Specification Manufacturer data measure 1. Symbol S290 S290/1 S290/2 2.

  • Page 27: Spare Parts Catalogue

    SPARE PARTS CATALOGUE How to use the catalogue. Spare parts catalogue includes other assemblies of the automatic conveyor planter, marked with proper numbers of tables. The catalogue should be used as follows: - determine the proper assembly the replaced part belongs to according to the tables, - find the necessary part on the assembly table following the reference number from the assembly drawing.
  • Page 28 Table 1. Vegetable planter Pos. in Part name KTM symbol Number of pieces S290 S290/1 S290/2 or standard number picture 3-row 4-row 5-row Planter frame set 290-001-000 Planter tank set 290-002-000 290-102-000 290-202-000 Planter chute assembly set 290-003-000 Planter drive set 290-004-000 Press wheel set 290-005-000...
  • Page 29 Table 2. Planter frame Pos. in Part name KTM symbol Number of pieces or standard number S290 S290/1 S290/2 picture 3-row 4-row 5-row Planter frame welded 290-001-001 Openwork platforms 290-001-002 Top beam of the chute assembly welded 290-003-001 290-103-001 290-203-001 Side shield base 290-010-000 Drive chain tensioner set...
  • Page 30 Table 3. Planter tank Pos. in Part name KTM symbol Number of pieces or standard number S290 S290/1 S290/2 picture 3-row 4-row 5-row Planter tank welded 290-002-001 290-102-001 290-202-001 Plastic chain keeper 290-002-002 Brush seal h5 25mm L=70 290-002-003 M6x16 bolt (DIN 933) 290-002-004 M6x12 bolt (DIN 933) 290-002-005...
  • Page 31 Table 4. Chute assembly set Pos. in Part name KTM symbol Number of pieces or standard number S290 S290/1 S290/2 picture 3-row 4-row 5-row Top beam of the chute assembly welded 290-003-001 290-103-001 290-203-001 Chute pipe 290-003-002 Marker welded 290-003-003 M12 U-bolt for fitting60x60 290-003-004 Brush seal h5 25mm L=105...
  • Page 32 Table 5. Vegetable planter drive Pos. in Part name KTM symbol Number of pieces or standard number S290 S290/1 S290/2 picture 3-row 4-row 5-row Drive axle Ø25x1535 290-004-001 Rubber wheel T105-70 R14 set 290-004-002 Road wheel hub T105-70 welded 290-004-003 Pins fastening the M12 road wheel hub 290-004-004 Threaded pin M8x20 (DIN 915)
  • Page 33 Table 6. Chain conveyor 5/8' (10B-1) with cups Pos. in Part name KTM symbol Number of pieces S290 S290/1 S290/2 or standard number picture 3-row 4-row 5-row Inner link 290-004-171 Outer link 290-004-172 Link with connection 290-004-173 Transfer cup Ø28 welded* 290-004-174 M5x20 bolt (DIN 933) 290-004-175...
  • Page 34 Table 7. Press wheel set Pos. in Part name KTM symbol Number of pieces or standard number S290 S290/1 S290/2 picture 3-row 4-row 5-row Press wheel set 290-005-000 Connection with sleeves welded 290-005-001 Support bracket for press wheel welded 290-005-002 Rubber wheel 4.10-3.50 set 290-005-003 Wheel tension spring...
  • Page 35 Table 8. Leveling roller Pos. in Part name KTM symbol Number of pieces or standard number S290 S290/1 S290/2 picture 3-row 4-row 5-row Leveling roller welded 290-006-001 Chain 290-006-002 M8 shackle 290-006-003 M16 nut (DIN 934) 290-006-004 Washer 16 (DIN126) 290-006-005 - 33 -...
