Exibel ADD009 Quick Start Manual

Laptop Charger
Art.no 38-8922 Model ADD009
Please read the entire instruction manual before using the
product and then save it for future reference. We reserve the
right for any errors in text or images and any necessary chan-
ges made to technical data. In the event of technical problems
or other queries, please contact our Customer Services (see
address details on the back).

Safety

• The incorrect charging current may damage your
computer. Make sure that the product can be used with
your computer before connecting it.
• Never attempt to disassemble or modify the product.
• Turn off your computer before connecting the product.
• Never expose the product to impacts, shocks or moisture.
• The product is intended for indoor use only.
• Never use the product if the mains lead or adapter is damaged.
• Disconnect the product from the power supply by
unplugging it from the wall socket. Make sure that the wall
socket and plug are easily accessible.
• The charger will become warm during use,
which is entirely normal.

Instructions for use

Note
• The charger is intended for use with laptops which operate on
a voltage of 18.5 V DC, 19.0 V DC, 19.5 V DC or 20.0 V DC.
• Make sure that the voltage of the charger is compatible
with your laptop before connecting it. Refer to the rating
plate on your laptop if you are unsure.
• The connector plug tips can only be connected to the plug
of the charger in one way. This is to ensure that the polarity
always remains correct.
1. Select the appropriate adapter plug tip for your laptop
and connect it to the connector plug, refer to the table.
The adapter plug tips are compatible with other makes of
computer than those listed in the table.
UNITED KINGDOM - CUSTOMER SERVICE contact number: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk
postal: Clas Ohlson Ltd, Aquilla House (First floor), 1 Becketts Wharf, Lower Teddington Road, Hampton Wick, Kingston Upon Thames, KT1 4ER
English
2. Connect the mains cable to the computer charger.
3. Plug the mains lead into a wall socket.
4. Make sure that the adapter tip is compatible with your
computer before connecting it.

Care and maintenance

Clean the product by wiping it with a dry cloth.

Troubleshooting guide

The laptop does not • Make sure that the correct
charge. connector tip is used and that
all leads are whole and correctly
connected to the charger, laptop
and wall socket.
• Is the wall socket energised?
• Check the condition of your
laptop battery to make sure that it
is capable of receiving a charge.

Responsible disposal

This symbol indicates that the product should
not be disposed of with general household
waste. This applies throughout the entire EU.
In order to prevent any harm to the environment
or health hazards caused by incorrect waste
disposal, the product must be handed in for
recycling so that the material can be disposed
of in a responsible manner. When recycling your product,
take it to your local collection facility or contact the place of
purchase. They will ensure that the product is disposed of in
an environmentally sound manner.

Specifications

Rated voltage 100–240 V AC
19.0 V DC
Output voltage
Max. power output 90.0 W
Mains lead 1.2 m
Connection cable 1.8 m

Adapters

Acer, Asus, Clevo,
Compaq, Fujitsu,
M Blue
Hitachi, HP, IBM,
Lenovo, NEC, Panaso-
nic, Sharp, Toshiba
Acer U Red
Asus 41 Black
Dell K1 Brown
HP 39 Turquoise
HP, Compaq K3· Purple
Lenovo 33 Yellow
Lenovo, IBM 16B Yellow
Samsung I Orange

Energy related Products (ErP) Directive

Model 38-8922
Input voltage AC 100-240 V
Input AC frequency 50-60 Hz
Output voltage DC 19.0 V
Output current 4.74 A
Output power 90.0 W
Average active efficiency 89.8 %
Efficiency at low load (10%) 89.6 %
No-load power consumption 0.09 W
