Summary of Contents for Alldaq ADQ-42
- Page 1 XXXXX ADQ-42/44/48 Rev. 1.0 EN ADQ-42/44/48 Manual Rev. 1.0 Programmable Electronic Load/Current Sink...
- Page 2 ADQ-42/44/48 Rev. 1.0 EN Imprint Manual ADQ-42/44/48 Rev. 1.0 Manufacturer and support ALLNET® and ALLDAQ® are registered trademarks of ALLNET® GmbH Computersysteme. For ques- tions, problems and product information please contact the manufacturer directly: ALLNET GmbH Computersysteme ® Division ALLDAQ...
-
Page 3: Table Of Contents
XXXXX ADQ-42/44/48 Rev. 1.0 EN Content 1. Introduction 1.1 Scope of delivery 1.2 Safety instructions 1.3 Installation and assembly site 1.4 Brief description 1.5 Control 2. Start of operation 2.1 Connection 3. Function groups 3.1 Block diagram 3.2 LED display status 3.3 Control options... -
Page 4: Introduction
Under no circumstances may you operate the device if it is damaged. If in doubt, contact our technical service department. Please read this manual carefully before installing the appliance! 1.1 Scope of delivery • ALLDAQ card of the ADQ-40 series incl. mating connector... -
Page 5: Safety Instructions
XXXXX ADQ-42/44/48 Rev. 1.0 EN 1.2 Safety instructions Be sure to observe the following instructions: • Never expose the appliance to direct sunlight when operating. • Never operate the appliance near heat sources. • Protect the device from moisture, dust, liquids and vapours. -
Page 6: Installation And Assembly Site
Channel-specific alert function for Usink, Isink and temperature shutdown per channel • Fan output (12V/1A) controllable by software • Heat sink temperature readable via software 1.5 Control • ALLDAQ ADQ-LINK-BUS • For control please use the ALLDAQ ADQ-SCU or ADQ-153. -
Page 7: Start Of Operation
XXXXX Start of operation ADQ-42/44/48 Rev. 1.0 EN 2. Start of operation 2.1 Connection The box should be handled with care to ensure that the device is not damaged by electrostatic discharge (ESD), mechanical stress or excessive current surges. Precautions should also be taken to... -
Page 8: Function Groups
XXXXX Funktion groups ADQ-42/44/48 Rev. 1.0 EN 3. Function groups 3.1 Block diagram Channels 0..7 ADQ-4X + Sense Timer and control logic - Sense Settings group Jumper ADQ-LINK (via cable) Isink = Temperature Setpoint setting EEPROM emergency shutdown 120R Adjusting resistor... -
Page 9: Control Options
Control via the ALLDAQ ADQ-LINK Bus is the recommended method of control for the ADQ-40 series. To do this, use the ADQ-4X app from the ALLDAQ driver. In addition to this APP, control via an API library is also possible. It allows full control over all functions of the ADQ-40 series. -
Page 10: Integrated Potentiometer
XXXXX Funktion groups ADQ-42/44/48 Rev. 1.0 EN 3.3.2 Integrated potentiometer With the analog control of the ADQ-40 series via the integrated potentiometers, the range of functions is limited to the simple setting of a current. The temperature emergency stop is also active to protect the hardware. -
Page 11: Pin Assignments
XXXXX Pin assignments ADQ-42/44/48 Rev. 1.0 EN 4. Pin assignments 4.1 Connector positions... -
Page 12: Pin Assignments
XXXXX Pin assignments ADQ-42/44/48 Rev. 1.0 EN 4.2 Pin assignments 4.2.1 Würth 5-pin ST8A / ST8B ADQ-LINK ADQ-LINK GND 5V ADQ-LINK 12V ADQ-LINK 4.2.2 Würth 2-pin Fan 12V Fan GND (switched) 4.2.3 Würth 6-pin ST0 … ST7 Sense + Sense -... -
Page 13: Mmcx
XXXXX Pin assignments ADQ-42/44/48 Rev. 1.0 EN 4.2.4 MMCX MMCX0 MMCX1 MMCX2 Shunt_CH - Sense_CH - GND_CH Shunt_CH + Sense_CH + Ext_Analog_Control... -
Page 14: Annex
XXXXX Annex ADQ-42/44/48 Rev. 1.0 EN 5. Annex 5.1 Specifications Element Condition Specification Channels 2, 4, or 8 potential-free current measu- ring channels Resolution/Sampling rate 16 bit / 7kHz Shunt-Type 20mΩ precision shunt Isenke measuring ranges 0 mA – 4000mA (125uA - 1 LSB) Usense measuring ranges 0 V –... - Page 15 XXXXX Annex ADQ-42/44/48 Rev. 1.0 EN Temperature range Operation 0..70 °C (standard), extended temperature range on request Humidity Operation 20%..55% (non-condensing) 20%..55% Storage (non-condensing) -40..100 °C Dimensions Top-hat rail according to ADQ-42: 105x120x75mm (LxWxH) ADQ-44: 175x120x75mm (LxWxH) DIN EN50022 ADQ-48: 315x120x75mm (LxWxH)
-
Page 16: Manufacturer And Support
XXXXX Annex ADQ-42/44/48 Rev. 1.0 EN 5.2 Manufacturer and support ALLNET® is a registered trademark of ALLNET® GmbH Computersysteme. For questions, problems and for product information of all kinds please contact the manufacturer directly: ALLNET® GmbH Computersysteme Division ALLDAQ Maistraße 2, D-82110 Germering E-mail: support@alldaq.com... -
Page 17: Ce Identification
If you have any questions or problems concerning the application, you can reach us during our normal opening hours at the following telephone number +49 (0)89 894 222 - 474 or by e-mail to: support@alldaq.com. - Page 18 ALLNET® GmbH Computersysteme Division ALLDAQ Maistrasse 2, D-82110 Germering E-Mail: support@alldaq.com Phone: +49 (0)89 894 222 – 474 Fax: +49 (0)89 894 222 – 33 Internet: www.alldaq.com...
