Summary of Contents for DEWEZE 400 Series

  • Page 3 TABLE OF CONTENTS OPERATION AND SERVICE Introduction ......................ii Warranty ......................2 Model Identification and Specifications ............. 3 Safety Symbols ..................... 4 Operating Safety & Safety Decals ............... 5 Operating the Flatbed ..................6 Operating Controls ....................7 Troubleshooting ....................8-9 Maintenance ......................
  • Page 4: Statement Of Warranty

    The Flatbed hydraulic and electrical systems are warranted for a period of ONE YEAR. The obligation of DewEze under this warranty is expressly limited, at our option, to replacement or repair at a service facility designated by DewEze or at the manufacturing plant in Harper, Kansas.
  • Page 8 add and full mark on dipstick. Use a high quality, multi-viscocity hydraulic oil.
  • Page 9 Note: See Annex A for installation instructions of New Generation valve and RF (remote) control.
  • Page 11: Safety Warning

    SAFETY WARNING! Do not exceed GVRW rating of truck when loading. Two bales can easily exceed the GVRW on a ¾ ton truck. A typical ¾ ton truck can haul 2,300 lbs. of payload in addition to the flatbed.
  • Page 22 HYDRAULIC...
  • Page 33 This Page Left Blank Intentionally...
  • Page 43 400 SERIES ANNEX A NEW GENERATION VALVES WITH RF CONTROL...
  • Page 48 DewEze Bale Loader Troubleshooting Sheet Note 1: Receiver chip Attached to antenna and DIP switch. Interprets signal from antenna, compares the received address with that of the DIP switch, and if they match, it sends outputs to logic chip. Valid Trans. pin will go to +3VDC when chip receives a valid transmission.
  • Page 49: Troubleshooting Steps

    Troubleshooting Steps 1. Check the +12VDC and Gnd wires to make sure that each is in the correct terminal. 2. Check the address set by the DIP switch on both the transmitter and receiver to make sure that they match. Warning: Transmitter and receiver circuit board are sensitive to electro- static discharge (ESD).
  • Page 54 2.5 - 3"...
